subcategories
(3rd category level)
Manufacturer:
(Category: 101)
-X-Way-700mm -Y-way-700mm -Z-way-700mm -Control-ITNC 530 -Spindle holder HSK A63 -Spindle speed-12000rpm -Plate changer with 7 pallets -Tool magasin with 120 -Internal cooling feeder-40bar -Spindle motor-20kW -Pallet size 500x500mm -Machine weight approx.16t -Top condition,to be visited under electricity
used
x-travel: 630 mmy-travel: 765 mmz-travel: 600 mm-A-axis table swivelling: -120/+30 (0.001) °-C-axis table rotating: 360 (0.001) °weight of the machine ca.: 14.5 tdimensions of the machine ca.: 4.5 x 2.4 x 3.52 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Forest-Line MajorMill 5-Axis CNC Gantry Mill Year: 1992/2008 Number of Axes: 5 Type of CNC Control: Fidia C20 CNC Control Retrofit in 2008 Table Size: 83.27" x 236" (2115x6000mm) X: 236” (6000mm) Y: 110.23” (2800mm) Z: 49.21” (1250mm) Max. Cutting Height: 62.99"(1600mm) Effective Width Between Columns: 94.5"(2400mm) Spindle Speeds, 3-Range: 10-3200 RPM Main Milling Head on Ram: Hard Steel Cartridge - 3 Speed Ranges - Equipped with an accessory holder plate with auto clamping: Indexing 2.5 degrees Spindle Taper: #50 ISO A-Axis Spindle Head Tilt: +/-95 Degrees B-Axis Spindle Head Swivel: 360 Degrees A-Station AAC: yes Automatic Head Changer: yes Automatic Attachment Changer (ACC):: Yes - 3 Heads Right Angle Head: 10 - 3200 RPM, 2.5 degree indexing DRC12 Head Attachment (double stepless rotation): 10 - 5000 RPM, (Double stepless rotation) Multiplying spindle exten ...
used
Year: 2000 Control: HEIDENHAIN TNC-426M axis stroke (X,Y,Z): 600x450x450 mmtable surface area: 850x530 mmspindle taper:: HSK A63 feeds -stepless-: 15000 mm/minSpeed: 20000 U/min.spindle drive: 16 kWrapid traverse: 22 m/minDimensions (L/W/H): 320X280X250 cmWeight: 6500 kgNumber of tools: 19 St.Vice: Manufacture: GRESSEL Coolant installation: The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Key data: 635 mm, 510 mm, 460 mm
Control Heidenhain iTNC 530 Travel x/y/z 635 mm / 510 mm / 460 mm Max. spindle speed 18,000 rpm Drive power of the main spindle 13 / 9 kW Tool holder SK 40 DIN 69871 Table clamping surface / max. table load 790 mm x 560 mm / 600 kg Tool changer with 30 positions Rapid traverse 30 m/min Total power requirement / machine weight 23 kVA / 4.5 t Space requirement 3.5 m x 4.0 m x 2.7 m
used
core drilling diameter max.: 16 mmbore depth: 485 mmswing diameter: x mmtable-size: 590x350 mmspindle turning speed range: 230-2300 U/minweight of the machine ca.: 0.4 tTable with digital read outMisc accessorieswww.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
X 860 mm Y 560 mm Z 600 mm Table 1000 x 560 mm ISO B40 DIN 69871
used
Control: HEIDENHAIN iTNC530 x-travel: 1500 mmy-travel: 800 mmz-travel: 1000 mmspindle head swivable left - right: 0-180 °c-axis: 360 (0.001) °b-axis: +/-90 (0.001) °table-size: 1430X800 mmtable diameter: 802 mmworkpiece weight max.: 1500 kgtool magazin:: 60 spindle turning speed range: -16000 U/minspindle taper: HSK63 feeds x/y/z -stepless: 0-30000 mm/minfeeds rotary table: 20 U/mindimensions of the machine ca.: 4x3.5x3 mweight of the machine ca.: 18 tThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Vertical Machining Center ( VMC ) AXA VSC-2-3000-M
used
Control: Manufacture: HEIDENHAIN iTNC 530 x-travel: 800 mmy-travel: 500 mmz-travel: 540 mmtable-size: 910x500 mmspindle turning speed range: 10000 U/mintool magazin:: 24 weight of the machine ca.: 8 tHEIDENHAIN TNC-426Prepared for the 4th axis www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Key data: 1000 mm, 900 mm, 1000 mm
For sale : Very nice Okuma horizontal machining center type MA-600HB. The machine is equipped with an OSP-E100M controller. The movement of the X, Y and Z axes is 1000 x 900 x 1000 mm. The machine has 2 pallets measuring 630 x 630 mm. Table indexing by 1 degree. The main engine power is 35 kW. In addition, the machine has 60 tool positions. a maximum speed of 10,000 rpm. SK-50 mounting, all tool holders are included with the machine. The maximum workpiece weight is 1200 kg. The machine weight is 26,000 kg. The machine can still be viewed under power, subject to prior sale.
used
Control: HEIDENHAIN TNC-430 x-travel: 800 mmy-travel: 600 mmz-travel: 500 mmB-axis (table): 280 mmtable swivelabel +/-: 220 (+/-110) °-C-axis table rotating: 360 °tool magazin:: 30 spindle taper: HSK63 spindle turning speed - stepless: -15000 U/minrapid traverse feeds rotary table: 36 U/minrapid travel x/y/z: 36 m/minOverall size: 3800X3600X3000 mmweight of the machine ca.: 8.5 tCoolant through spindle: pressure: 40 Bar3D measuring tracer: RENISHAW Chip conveyor: Coolant installation: SIEMENS 840Dwww.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Table Size : 2250 x 1000 mm Travels X,Y,Z : 2050 x 1000 x 700 mm Distance between columns : 1200 mm Rapid feeds X, Y, Z : 40 / 30 / 24 m/min Spindle Taper : BT40 Big Plus Spindle speed : 20 000 Rpm Number of tools : 40 Control Unit Fanuc 18M
used
Control: HEIDENHAIN iTNC-530 x-travel: 885 mmy-travel: 800 mmz-travel: 520 mmB-axis (table): +30/-120 °c-axis: 360 °table-size: 600x500 mmtool magazin:: 60 spindle taper ISO: 40 Big Plusspindle turning speed - stepless: 15000 U/mintotal power requirement: 25 kWrapid travel x/y/z: 36 mm/minrapid traverse (slewing motion): 60 U/minrapid traverse feeds rotary table: 100 U/mindimensions of the machine ca.: 3.8x3.6x3.0 mweight of the machine ca.: 12,1 tCoolant through spindle: pressure: 20 bar3D measuring tracer: RENISHAW Chip conveyor: Coolant installation: The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Manufacturer NEWAY Model VM 1160 H CNC FANUC 0i MF PLUS 15” TOUCH SCREEN Table Table surface 1.100 x 600 mm Max weight allowed on table 750 kg T slots 5 18 mm 100 Capacities Longitudinal Travel (X- Axis) 1.000 mm Transversal Travel (Y-Axis) 600 mm Vertical Travel (Z- Axis) 560 mm Max drilling dia Ø40mm. Max tapping dia M20 mm Milling capacity 200 cm3/min Feeds Rapid feed (X, Y Axis) 36.000 mm/min Rapid feed (Z Axis) 30.000 mm/min Cutting feedrate (X, Y, Z) 1-10.000 mm/min Positioning/ Repetitivity accuracy 3 axis 0.008/0.005 mm. Main spindle Taper BT40 Spindle Speeds 12.000 rpm Spindle head 11/18.5 kW Spindle torque 44.8/59.6 Nm Distance from spindle nose to table 150-710 mm. Distance from spindle center to z axis 660 mm. Automatic Tool Changer Positions in magazine 24 Max tool diameter 80 mm Max tool length 300 mm Max tool weight 8 kg Tool change ...
used
Control: Manufacture: HEIDENHAIN x-travel: 650 mmy-travel: 500 mmz-travel: 450 mmb-axis: -5/+95 °table surface area: 1000x600 mmspindle turning speed - stepless: 12000 U/minvoltage: 400 Vdimensions of the machine ca.: 3400x3000x2300 mmxmmxmmweight of the machine ca.: 5.5 tThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Manufacturer DOOSAN Model NM 410HS Year 2008 CNC CNC Fanuc 2liM-B Table Table surface 920 × 430 mm Max weight allowed on table 600 kg T slots 4x125x18H Travels and feeds Travels (X/Y/Z) 762/410/510 mm Distance from table top to nose head 150 – 660 mm Distance from spindle center to column guideway 457 mm. Rapid feed (X, Y, Z Axis) 48.000 mm/min Cutting feedrate (X, Y, Z) 1-24.000 mm/min Main spindle Taper BT40 Spindle Speeds 20.000 rpm Spindle head 11/18.5 kW Spindle torque 60 Nm Automatic Tool Changer Postions in magazine 3 0 Tool selection type RANDOM Max tool diameter (full magazine) 90 mm Max tool diameter (alternative) 150 mm Max tool length 300 mm Max tool weight 8 kg Tool change time (tool to tool) 1.5 s Equipment Rigid Tapping INCLUDED Portable handwheel INCLUDED Longitudinal chip conveyor INCLUDED Internal coolant INCLUDED Coolant t ...
used
bore capacity in steel (diameter): 26 mmthroat: 290 mmbore stroke: 160 mmspindle turning speed - stepless: 120-2200 U/minweight of the machine ca.: 460 kgdimensions of the machine ca.: 500 x 800 x 1900 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
FAGIMA Jazz L5 AX 5-axis continuous machining centre TECHNICAL CHARACTERISTICS: Year: 2018 CN Type: HEIDENHAIN iTNC 640 Number of continuous axes: 5 X-axis travel: 2000 [mm] Y-axis travel: 600 [mm] Z-axis stroke: 550 [mm] X, Y and Z axis travel speed: 20000 [mm/min] Fast travel speed X, Y and Z: 40000 [mm/min] Acceleration axis displacement: 2.5 [mm/sec²] Minimum distance. Spindle/Table: 30 [mm] Table length: 1250 [mm] Table width: 800 [mm] Max. weight Permissible on the table: 500 [Kg] Tilting table area: 600 x 600 [mm] Angular stroke C-axis: table revolution: 360 [°] Max. speed C-axis: 25 [rpm] Angular stroke axis B: -110 / +110 [°] Pin Attachment: ISO 40 Max. speed Spindle: 15000 [RPM] Spindle power: 17 [kW] Number of tool magazine stations: 80 Max. length Tool size: 300 [mm] Max. weight per tool: 7 [Kg] Max. total weight Eligible tool magazine: 400 [Kg ...
used
core drilling diameter max.: 20 mmbore depth: 900 mmlongitudinal travel: 700 mmcross travel: 300 mmspindle travel: 600 mmw-axis: 750 mmweight of the machine ca.: 1.6 tdimensions of the machine ca.: 3.5 x 2.1 x 1.75 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
MIKRON UCP 600 VARIO machining center TECHNICAL CHARACTERISTICS: Year: 2006 CN Type: HEIDENHAIN iTNC 530 Number of continuous axes: 5 X-axis travel: 600 [mm] Y-axis travel: 450 [mm] Z-axis travel: 450 [mm] Table length: 325 [mm] Table width: 325 [mm] Max. weight Permissible on the table: 200 [Kg] Table area Ø: 450 [mm] Pin Attachment: HSK-A 63 Minimum speed. Spindle: 100 [RPM] Max. speed Spindle: 20000 [RPM] Spindle power: 13.5 [kW] Number of tool magazine stations: 120 Max. length Tool Size: 250 [mm] Max. weight per tool: 6 [Kg] Max. diameter Tool Size: 125 [mm] Supply voltage: 400 [V] Machine Weight: 7700 [Kg] Tool changer weight: 800 [Kg] Palletizer weight: 1200 [Kg] Visible machine under power for testing at our premises, by appointment. Price excl. VAT on request, truck loading included. Possibility of shipping throughout France as well as intern ...
used
Control: Heidenhain iTNC 530 x-travel: 450 mmy-travel: 400 mmz-travel: 480 mmb-axis: -95/+30 °c-axis: 360 °spindle turning speed - stepless: 12000 U/minweight of the machine ca.: 4.5 tdimensions of the machine ca.: 2.4 x 3.0 x 2.5 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Key data: 1000 mm, 600 mm, 700 mm
ZPS MCFV 1060 LR Year of construction: 1999 Control: Heidenhain TNC 426 CB CNC Machining Center Travel: X/Y/Z: 1000/600/700mm Spindle speed: up to 8,000 rpm Tool changer: 24 speed Table size: 1270 x 590 mm Mounting: SK 40 Weight: 6.7 tons Conveyor Milling spindle cooling Safety circuit for the use of high-frequency spindles Coolant device via spray nozzles Air supply through internal spindle (ILZ)
used
x-travel: 550 mmy-travel: 410 mmz-travel: 450 mmb-axis: +110/-110 °spindle turning speed range: -15000 U/minspindle taper: BT Big Plus 40 tool change unit: 40x size of pallet: 2x D-250 mmweight of the machine ca.: 8.6 t5 axes machining centerFANUC G-Tech 30iCoolant through spindle3D measuring probeTool measuring deviceMisc palletsMisc tool holdersMore details on www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Inv. Num. : 7527 Type: VMX 42i Produzent: HURCO Erzeugt: 2014 Parametern: Einschaltstunden: 2100 h Arbeitstischlänge: 1270 mm Arbeitstischbreite: 610 mm Maximale Tischbelastung (gleichmäßig): 1750 kg Maximale Drehzahl der Spindel: 12000 1/min Verfahrwege X-Achse: 1067 mm Verfahrwege Y-Achse: 610 mm Verfahrwege Z-Achse: 610 mm Antriebsleistung der Werkstückspindel: 18 kW Minimale Vorschubgeschwindigkeit Z-Achse: 38/38/32 mm/s Maschinengewicht: 6850 kg Ausstattung: Späneförderer 20x Werkzeughalter
used
spindle diameter: 127 mmx-travel: 2000 mmy-travel: 1000 mmvertical movement: 1300 mmtable-size: 1400x1250 mmweight of the machine ca.: 20 tDigital read-outUniversal milling headFace plateMisc accessorieswww.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Inv. Num. : 7531 Type: VMC 750 Producer: MAS Created: 2000 Parameters: Control system: VICKERS ACRAMATIC A2100 Work table length: 1000 mm Work table width: 500 mm X-axis travel: 750 mm Y-axis travel: 500 mm Z-axis travel: 500 mm Machine weight: 4000 kg Equipment: Technical Documentation
used
Control: HEIDENHAIN iTNC-530 for axes: 5 x-travel: 712 mmy-travel: 508 mmz-travel: 515 mm-A-axis table swivelling: +30/-120 °-C-axis table rotating: 360 °rotary table dia.: 330 mmno. of tools in magazin: 60 max. tool diameter: 88 mmmax. tool-dia with free toolbox: 125 mmmax. tool length: 280 mmmax. tool weight: 7 kgspindle taper: SK40 Big Plus spindle turning speed range: -15000 U/minpower capacity - milling spindle: 25 kWweight of the machine ca.: 12.8 tdimensions of the machine ca.: 303x395x367 cm3D measuring tracer: RENISHAW Zero point clamping system:: LANG TECHNIK Coolant through spindle: pressure: 20 barThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Key data: 10000 mm, 3000 mm, 2000 mm
Inv. Num. : 7444 Type: FC 10000 CNC 5X Producer: SAHOS Created: 2008 Parameters: Control system: HEIDENHAIN Spindle drive power: 22 kW X-axis travel: 10000 mm Y-axis travel: 3000 mm Z-axis travel: 2000 mm Maximum feed speed axis X: 60 m/min Maximum feed speed axis Y: 30 m/min Maximum feed speed axis Z: 30 m/min Machine weight: 14,500 kg
used
spindle diameter: 75 mmx-travel: 800 mmy-travel: 1300 mmvertical movement: 1000 mmspindle taper MT: 5 spindle turning speed range: 14-1500 U/mintable-size: 1000x850 mmweight of the machine ca.: 6.7 tMisc accessorieswww.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
