FAGIMA used machine for sale

FAGIMA Jazz L5 AX 5-axis continuous machining centre TECHNICAL CHARACTERISTICS: Year: 2018 CN Type: HEIDENHAIN iTNC 640 Number of continuous axes: 5 X-axis travel: 2000 [mm] Y-axis travel: 600 [mm] Z-axis stroke: 550 [mm] X, Y and Z axis travel speed: 20000 [mm/min] Fast travel speed X, Y and Z: 40000 [mm/min] Acceleration axis displacement: 2.5 [mm/sec²] Minimum distance. Spindle/Table: 30 [mm] Table length: 1250 [mm] Table width: 800 [mm] Max. weight Permissible on the table: 500 [Kg] Tilting table area: 600 x 600 [mm] Angular stroke C-axis: table revolution: 360 [°] Max. speed C-axis: 25 [rpm] Angular stroke axis B: -110 / +110 [°] Pin Attachment: ISO 40 Max. speed Spindle: 15000 [RPM] Spindle power: 17 [kW] Number of tool magazine stations: 80 Max. length Tool size: 300 [mm] Max. weight per tool: 7 [Kg] Max. total weight Eligible tool magazine: 400 [Kg ...

Key data: 2000 mm, 600 mm, 550 mm

with CNC control, Fabr. HEIDENHAIN, type: TNC 640, travel: X-axis: 2000 mm, Y-axis: 600 mm, Z-axis: 550 mm, table size: 1250x800 mm, max. spindle speed: 12,000 rpm, power consumption: 25 kW, with autom. Tool changer: 100-fold, tool holder: SK40 with IKZ coolant supply and chip conveyor

Machining center FAGIMA FA 1250 BIG Make: FAGIMA Model: FA 1250 BIG YEAR 2010 X-AXIS TRAVEL 1250 mm Y-AXIS TRAVEL 700 mm Z-AXIS TRAVEL 620 mm DISTANCE SPINDLE NOSE-TABLE 100 mm RAPID FEEDS X-Y-Z 40 – 36 – 28 m/min SPINDLE 10000 rpm; 22-35 kW; ISO 40 – DIN TABLE SIZE 600 x 1500 mm MAX ADMITTED LOAD 1400 Kg TOOL MAGAZINE CHAIN-TYPE ; 24 POS MAX TOOL DIAMETER 80 (125) mm MAX TOOL LENGHT 300 mm MAX TOOL WEIGHT 8 Kg CONTROL UNIT HEIDENHAIN iTNC 530 WEIGHT 8500 Kg OVERALL DIMENSIONS 2370 x 3350 x 3180 mm ACCESSORIES SWARF CONVEYOR ; PORTABLE HANDWHEEL
