Model
(Manufacturer: ALZMETALL)
used
used
see side sheet below, with 2-spindle drill head Franz X. LINDNER SBS-2/2, spindle distance 300 mm, (translation 1:1)
used
Alzmetall AB4SJ Tool holder MK4 automatic feed with 3 feed speeds 2 shoot stages and infinitely variable speed control right left barrel, thread cutting device Cooling agent device in the foot Round table with holes without rev counter Machine hood modern made of plastic with cracks and loechers Speed: 80-710 rpm Table diameter: 450 mm Max distance from spindle to foot: 1200 mm Extension to center spindle: 170 mm Machine hoe approx. 200 cm Bt323s8 SPECIAL PRICE due to visually poor condition according to photos, technically usable condition, the drill is not locked at the shaft drill spindle tool holder in the rotational motion (see photos). If the drill is not firmly in the drill spindle, it rotates through. Special price
used
Length: 800mm, width: 600mm, height: 2000mm, weight: 825kg.
used
Max. rotational speed: 7500/min.
used
Rotational speed: 60-1200/min, chain: A3/ 26V.
used
Drilling capacity steel/ cast iron: 35/45mm, length: 1100mm, width: 600mm, height: 2050mm.
bore capacity in steel (diameter): 45 mm throat: 345 mm bore stroke: 180 mm taper MK: 4 MK table-size: 720 x 560 mm feeds: 0,15 - 0,2 - 0,3 - 0,36 mm/U turning speeds: 30 - 765 U/min total power requirement: 3,4 KW weight of the machine ca.: 0,95 t dimensions: 1,2 x 0,8 x 2,1 m Automatic feed Spindle speeds infinitely adjustable Emergency stop facility Footswitch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
bore capacity in steel (diameter): 45 mm throat: 350 mm bore stroke: 180 mm taper MK: 4 MK table-size: 720 x 560 mm feeds: 0,15 - 0,2 - 0,3 - 0,36 mm/U turning speeds: 30 - 765 U/min total power requirement: 3,4 KW weight of the machine ca.: 0,95 t dimensions: 1,2 x 0,8 x 2,3 m Automatic feed Spindle speeds infinitely adjustable Coolant system Emergency stop facility Footswitch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
distance spindle /table:min /max 190 / 570 mm distance spindle /table:190 - 570 mm surface area:650 x 300 mm Boring power:in GG 20 40 mm bore capacity in steel:ST 60 32 mm turning speed range::50 - 5000 UpM total power requirement:2,2 kW threading:GG 20 M30 threading::ST 60 M 24 weight of the machine ca.:1400 kg table load:max. 150 kg table height:770 mm traversing speed:max X-, Y- u. W-Achse 5 m/min max. traversing speed:Z-Achse 3 m/min w-axis:380 mm workpiece height max.:495 mm tool changing time:ca. 3 sec x-travel:450 mm y-travel:300 mm z-travel:180 mm workpiece weight:1,5 kg
used
Description: Countersinking stroke 180 mm, max. 3000 rpm, table 600 x 450 mm, table height adjustable, Attention: without vice Approx. Onsite Dimension. (l x w x h): 800 x 1,400 x 2,100 mm, weight approx.: 1,600 kg
used
serial number: 3070 taper MK: 4 weight: 700 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Description: countersink 180 mm, max. 3000 rpm, table 600 x 450 mm, table height adjustable, Attention: without vice weight approx.: 1,600 kg, Approx. Onsite Dimension. (l x w x h): 800 x 1,400 x 2,100 mm
used
Description: Serial number 5151 Table diameter 350 mm Includes vice, jaw width ,125 mm turning speed range: 63 bis 1750 rpm, weight approx.: 600 kg, Approx. Onsite Dimension. (l x w x h): 1,000 x 600 x 1,800 mm
new
bore capacity in steel St 60: 25 mm Drilling capacity in St 60: 30 mm threading in St 60: M 16 : M 20 Short spindle: MK 3 spindle stroke: 140 mm throat: 293 mm column diameter: 115 mm Machine table - usable table surface: 514x360 mm T-Slots Amount - Width - Distance: 2x14x224 mm distance spindle - column min./max.: 132/724 mm feed: von Hand 0: stufenlos Spindle Speed: 225-4300 U/min. engine: 1,0/1,6 kW voltage: 400 V Standard equipment: - 7 TFT LCD display with touch function: Manual input of spindle speed set value Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status indicators and warnings on the display Service information Selectable operating language: DE/EN/FR/ES/IT/NL/RU - Thread cutting device, for thread cutting with stop, max. 6 threads/min (thread cutting capacity depending on spi ...
new
: 34 mm : 40 mm : 40 mm : MK 4 : 100-1.800 U/min. throat: 300 mm : 615x430 mm : 2 x 14 x 224 mm : 138/688 mm column diameter: 145 mm spindle stroke: 160 mm feeds: 0,1-0,2-0,3-0,4 mm/U Machine height: 1865 mm total power requirement: 1,4/2,2 kW Standard equipment: - Electromagnetic feed clutch with overload protection and electrical Cross Handle Switches - Main switch lockable - Motor protection switch - Mushroom pushbutton (latching) for EMERGENCY STOP in the front panel - Speed adjustment stepless - Speed display digital - Protection class IP 54 - Motor insulation class F - Spindle protection with electrical protection Pos. 20.1 Tapping device with foot switch, for thread cutting with Stop, max. 6 threads/min., (Tapping power dependent on spindle speed) Pos. 25. Coolant device B, consisting of: separate container (33 l), pump with Motor protection switch, complete fitting The data for ...
used
Description: Including vice (jaw width: ,140 mm) turning speed range: 50 - 1220 rpm, table surface area l x w : 900x650 mm, weight approx.: 1,600 kg, Approx. Onsite Dimension. (l x w x h): 1,300 x 800 x 2,300 mm
used
Description: Speed (rpm): 1500 / 3000 Weight (kg): 260 Table dimensions (LxW) (mm): 515x360 Power (kW): 1.0 / 1.6 Spindle speed (rpm): 160 - 2250 Column Ø (mm): 115 Projection (mm): 293 Short spindle: MK 3 Spindle stroke (mm): 120 Drilling capacity steel/cast iron (mm): 32/38 Thread cutting steel/cast iron (mm): M24/M30 weight approx.: 280 kg, Approx. Onsite Dimension. (l x w x h): 700 x 600 x 2,000 mm
used
: 40 mm : M 24 : M 30 : MK 3 bore stroke: 120 mm throat: 293 mm column diameter: 115 mm : 514x360 mm : 2 x 14 x 224 mm : 117/701 mm spindle turning speed range: 160-2.250 UpM total power requirement: 1,45/1,9 kW height of the machine: 1840 mm weight of the machine ca.: 285 kg Standard equipment: - Mushroom pushbutton (latching) for EMERGENCY STOP - Reversing switch for right-left rotation - Motor protection switch - Speed adjustment stepless - Speed display digital - Feed overload protection - Protection IP 54 - Connector (fully assembled, cable length 2 m) - Spindle protection with electrical protection The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Description: Voltage 380 V , Table support 300 x 400 mm , Stroke 1500 mm , Table adjustable in height , Without additional accessories Without CE certificate weight approx.: 190 kg, Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 2,000 mm
used
Description: Machine number: 9217 Spindle speed: 132 - 2800 rpm Table dimensions: 400 x 300 mm With 2 grooves and a vice Jaw width: 100 mm weight approx.: 400 kg, Approx. Onsite Dimension. (l x w x h): 1,000 x 700 x 1,800 mm
used
Description: 3 phase A.C. 380 V control voltage 220 V  , Approx. Onsite Dimension. (l x w x h): 1,300 x 1,250 x 2,450 mm, weight approx.: 1,420 kg
used
This 5-axis ALZMETALL GS600E was manufactured in 2015. Key features include a Heidenhain TNC 640 control system, 18,000 rpm spindle with HSK A63, and cutting-edge chip conveyor for impeccable coolant cleaning. Its fitted with tool measuring via laser and a working probe for higher accuracy. The machine offers extensive production capabilities with its automatic door and air sealing for the linear measuring system, ensuring efficiency. This machine represents exceptional value for precision machining needs. Contact us for further details regarding this ALZMETALL GS600E universal machining center.
used
This 5-axis ALZMETALL GS800/5-T universal machining centre was manufactured in 2015. It boasts advanced technology including Heidenhain TNC 640 control, 30,000 rpm capability with HSK A63, and high precision packages ensuring remarkable exactness up to TP 0.005mm for X, Y, Z axes. Enhanced features like dynamic collision monitoring, tool measuring via laser and a robust security compound window combine to offer peak performance and safety. The ALZMETALL GS800/5-T machine we have for sale is equipped to increase productivity and precision in complex machining tasks. For more information about this ALZMETALL GS800/5-T universal machining centre, please reach out to us.
used
Drill, pillar drill, column drill, column drill -Manufacturer: Alzmetall, pillar drilling machine type AB5/S -Engine: VKS 3 kW -Speed: 40 - 800 rpm, continuously variable right-left rotation -Feed: 0.1 - 0.14 - 0.2 - 0.28 - 0.4 mm/rev. -Table size: Ø 500 mm, travel 470 mm -Spindle holder: MK5 -Spindle stroke: 240 mm -Projection: 380 mm -Column Ø: 220 mm -Dimensions: 1450/680/H2160 mm -Weight: 1262 kg
used
Description: Serial number 18067 Includes 2nd clamping table approx. 400 x 380 mm turning speed range: 30 bis 3000 rpm, table surface area l x w : 500x370 mm, weight approx.: 600 kg, Approx. Onsite Dimension. (l x w x h): 900 x 750 x 1,900 mm
used
: 40 mm threading in St 60: M24 threading in GG 20: M30 : MK 3 spindle stroke: 120 mm : 160 - 2250 U/min. throat: 293 mm column diameter: 115 mm : 514 x 360 mm : 2 x 14 x 224 mm distance spindle /table: min. 117 / max. 701 mm feed: 0,1 + 0,2 mm/U height of the machine: ca. 1840 mm weight of the machine ca.: ca. 260 kg Standard equipment: - 7 TFT LCD display with touch function: Manual input of spindle speed set value Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status indicators and warnings on the display Service information Selectable operating language: DE/EN/FR/ES/IT/NL/RU - Thread cutting device, for thread cutting with stop, max. 6thread/min (thread cutting capacity depending on spindle speed), thread depth adjustable via depth stop and on the TFT LCD display (4 tools) - Infinitely v ...
new
Drilling capacity in St 60: 40 mm threading in St 60: M 24 mm threading in GG 20: M 30 bore stroke: 120 mm Short spindle: MK 3 throat: 293 mm column diameter: 115 mm Machine table - usable table surface: 514x360 mm T-Slots Amount - Width - Distance: 2 x 14 x 224 mm Distance spindle - machine table min./max.: 117/701 mm feed: 0,10 + 0,20 mm/U spindle turning speed range: 160-2.250 UpM total power requirement: 1,45/1,9 kW height of the machine: 1840 mm Standard equipment: - Mushroom pushbutton (latching) for EMERGENCY STOP - Reversing switch for right-left rotation - Motor protection switch - Speed adjustment stepless - Speed display digital - Feed overload protection - Protection IP 54 - Connector (fully assembled, cable length 2 m) - Spindle protection with electrical protection Pos. 25 Coolant device B, consisting of: separate container (33l), Pump with motor protection switch, complete ...
new
: 34 mm : 40 mm : 40 mm : MK 4 : 100-1.800 U/min. throat: 300 mm : 615x430 mm : 2 x 14 x 224 mm : 138/688 mm column diameter: 145 mm spindle stroke: 160 mm feeds: 0,1-0,2-0,3-0,4 mm/U Machine height: 1865 mm total power requirement: 1,4/2,2 kW Standard equipment: - Electromagnetic feed clutch with overload protection and electrical Cross Handle Switches - Main switch lockable - Motor protection switch - Mushroom pushbutton (latching) for EMERGENCY STOP in the front panel - Speed adjustment stepless - Speed display digital - Protection class IP 54 - Motor insulation class F - Spindle protection with electrical protection Pos. 20.1 Tapping device with foot switch, for thread cutting with Stop, max. 6 threads/min., (Tapping power dependent on spindle speed) Pos. 25. Coolant device B, consisting of: separate container (33 l), pump with Motor protection switch, complete fitting The data for ...
used
Boring power: 32.0 mm bore capacity in cast iron: 35.0 mm morse taper: MK 3 spindle stroke: 160 mm throat: 293 mm column diameter: 115 mm table:: 400 x 500 mm turning speeds: 125 - 1050 U/min total power requirement: 0.55 / 0.80 kW weight: 200 kg range L-W-H: 625 x 950 x 1840 mm from a training workshop maintained condition () Furnishing: - V-belt operated column drilling machine - adjustable drilling depth stop - manual spindle feed via cross handle - Work table with 2x T-slots - Pole-changing drive motor - Table height adjustment via hand crank - Connection cable including 16A plug Machine link: http://mhp.logotech.de/hpm/v7/Datenblatt/datenblatt.php?machineno=1008 -9103747 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
