used
1 x CNC table boring mill Wotan Rapid 1 Year of construction: overhauled / with new control system 2008 X- 2000mm Y-1600mm Z- 600mm W-1000mm B- 360 degrees Table clamping surface : 1250 x1600mm Table load: 6000 kg Spindle speed : 1600 rpm Control: Heidenhain it 530 Controlled axes 5
used
1 x CNC table boring mill Wotan Rapid 1 Year of manufacture: overhauled / with new control system 2012 X- 2000mm Y-1600mm Z- 600mm W-1000mm B- 360 degrees Table clamping surface : 1250 x1600mm Table load: 6000 kg Spindle speed : 1600 rpm Control: Heidenhain it 530 Controlled axes 5
used
INTERNAL GRINDING MACHINE Make: Wotan Model: RJ 315 internal grinding diameter: 1100 mm external grinding diameter: 1200 mm Other info: The machine is in excellent condition and is complete in all its parts and accessories. In particular, this grinding machine is equipped with the following optionals: -Face grinding attachment -External grinding attachment -DRO
used
Tablе stroke 500 mm Max grinding depth 250 mm Grinding diameter 500 mm max (with water protection 450 mm) To sand bore diameter 300 mm Swivel range of the workpiece headstock 25 max Grindable cone angle 50 Rotational speed of the workpiece spindle U / MIN 20-400 Table speed infinitely einstallbar m / min 0.1-8
new
UNUSED: Facinghead of a Wotan BF 160 Horizontal borer.
used
Horizontal borer Wotan B105Y Spindle: 120 mm Travels: -X: 3000 mm -Y: 1450 mm -Z: 1280 mm Table: -1400 x 3000 mm -Rotating part: 1130 x 1500 mm (manually rotated to any degrees) -Max load: 7 tn Machine weight: about 25 ton
used
-Spindle diameter 160 mm -Spindle SK 50 DIN 69871 - spindle power 90 kW -X-axis 16,000 mm -Y-axis 4.455 mm -W-axis 900 mm -Z-axis 800 mm
used
Tischaufspannflaeche Max Tischbelastung 25 to . groove distance 180 mms table movement 1,000 mms table rotation B axis 360? Aufspannflaeche 1600 x 2,500 mms number of the grooves 9 table overtakes completely in 2012 anew SIEMENS impulses, new MOOR GROVE graduations
used
spindle diameter: 90 mm x-travel: 1400 mm y-travel: 1250 mm z-travel: 1300 mm table surface area: 1100x1400 mm spindle travel: 800 mm digital readout: spindle turning speed range: 1000 U/min spindle taper MT: 5 total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
spindle diameter: 130 mm x-travel: 5000 mm y-travel: 2000 mm z-travel: 1000 mm table surface area: 5100x1520 mm spindle taper ISO: 50 spindle travel: 1100 mm digital readout: spindle turning speed range: 2,8-1000 U/min Feed: 0,025-10 mm/U Feed: 4-1600 mm/min total power requirement: kW weight of the machine ca.: 35 t dimensions of the machine ca.: 11,5x5,4 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Sliding support, linear drive, clamping plate, unit carrier, milled surface, welding table, welding table -Spare part of: a Wotan table boring machine -compatible with: clamping plate ID 21339 -Width at the top: 80 mm -Width at the bottom: 270 mm -Length: 2200 mm -Height: 215 mm -Number: 2x available -Price: complete for both -Transport dimensions: 2200/600 / H300 mm -Weight: 556 kg
used
Spindle for plate boring mill, table boring mill, boring mill, milling machine, quill, boring head, support bearing, spindle support bearing -for quill: 80 mm -Drive pin: 12 mm -Pinole head: ball bearing -Recess recording: 250 mm -Support bolt circle: 330 mm -Recording holes: 21 mm -Dimensions: 385/385/H373 mm -Weight: 58.5 kg
used
Clamping plate with T-slots and cross table, plate field, welding table, welding table, plate boring machine, T-slot plate -T-grooved plate comes from: from a WOTAN boring mill -compatible with: linear drive ID 22786 -Travel: 1110 mm -Clamping plate: 1000 x 1260 mm -Plate thickness: mm -Table height: mm -Plate is: Solid -Groove width: 21 mm -Dimensions: 2470/1070/H885 mm -Weight: 2200 kg
used
Spindle diameter: 130 mm Longitudinal X: 10000 mm Vertical Y: 3500 mm Cross Z: 1000 mm Positions ATC: 0 Table length: 3000 mm Table width: 3000 mm Number of tables: 1 CNC Brand: _Unknown / Other CNC Model: Bosch CC 200 Universal milling head Angular indexing vertical milling head V Axis table 1600 mm X - Travel: 10000mm Y - Travel: 3500mm Z - Travel: 1000mm W - Travel: 900mm Table Length: 3000mm Table Width: 3000mm Table load: 25000 Speeds / ranges:800/2500Rpm Power: 63kW Ram size: 400 x 400mm Spindle Taper: 50ISO/Bt/Mk Feed rate X-Axis:5000mm/min. Feed rate Y-Axis:5000mm/min. Feed rate Z-Axis:5000mm/min. Feed rate W-Axis:5000mm/min. Length:   ...
used
Drilling and milling machine make WOTAN type B 75 TFabr. -No: 58252 Year of construction 1965Spindle diameter: 75 mmTransverse travel = X: 800 mmLongitudinal path = Y: 800 mmVertical path = Z: 800 mmSpindle stroke = W: 600 mmDrill spindle inner cone: ISO 40Drilling depth in one go without quick tension: 600 mmwith quick tension: 550 mmVertical adjustment above table: 0 - 800 mm20 spindle speeds: 12.5 x 1000 rpm.Table mounting surface: 800 x 1000 mmSwivel range: 360 °Transverse movement: 800 mmLongitudinal movement: 800 mm27 feed steps: 0.02 - 8 mm / revRapid traverse: 2.4 m / min12 metric thread pitches: 0.5 - 8 mmFaceplate diameter: 420 mmmax. facing diameter: 560 mmMovement of the slide valve: 120 mmFeed range: 0.04 - 16 mm / revDrive power: 9 hpDimensions approx: 3400 x 1800 x 2500 mmWeight approx: 6800 kgWith- 3-axis digital display- Cooling devicedespite the year of construction in ...
used
Spindle diameter: 130 mm Cross X: 1800 mm Vertical Y: 1700 mm Table length: 1400 mm Table width: 1120 mm Positions ATC: 0 Number of pallets: 0 CNC Brand: Heidenhain CNC Model: TNC 415 MAKE WOTAN Spain TYPE CUTMAX 2 YEAR 1995 SPECIFICATIONS Controll HeidenHain TNC 415 Floor or table type borer Table type borer X - Travel 1800 mm Y - Travel 1700 mm Z - Travel 600 mm W - Travel 1500 mm Spindle Diameter Ø 130 mm Spindle Taper ISO 50 kW power on spindle 30 kW Spindle speeds / ranges 0 - 3000 Rpm Table Length x Width 1400 x 1120 mm Table load in kG 6000 Kg Number off controlled axis 5 DIMENSIONS Length &nbs ...
used
Spindle diameter: 130 mm Cross X: 2000 mm Vertical Y: 1600 mm Table length: 1400 mm Table width: 1120 mm Positions ATC: 0 Number of pallets: 0 CNC Brand: Siemens CNC Model: 840 D - 5 Axis MAKE WOTAN Germany TYPE Rapid 2 YEAR 200. SPECIFICATIONS Controll Siemens 840D - 5 Axis Floor or table type borer Table type borer X - Travel 2000 mm Y - Travel 1600 mm Z - Travel 800 mm W - Travel 1000 mm Spindle Diameter Ø 130 mm Spindle Taper ISO 50 kW power on spindle 40 kW Spindle speeds / ranges 2000 Rpm Table Length x Width 1400 x 1120 mm Table load in kG 6000 Kg Number off controlled axis 5 DIMENSIONS Length 5000 ...
used
Spindle diameter: 0 mm Cross X: 800 mm Vertical Y: 800 mm Table length: 1000 mm Table width: 800 mm Positions ATC: 0 Number of pallets: 0 X – Travel: 800mm Y – Travel: 800mm Z – Travel: 1.000mm W – Travel: 550mm Table Length: 1.000mm Table Width: 800mm Table load: 1.500Kg Speeds / ranges:1000Rpm Power: 6,7 kW Spindle Taper: 40ISO/Bt/Mk Feed rate X-Axis:2.400mm/min. Feed rate Y-Axis:2.400mm/min. Feed rate Z-Axis:2.400mm/min. Feed rate W-Axis:2.400mm/min. Length: 4.000 mm Width: 2.000 mm Height: 2.300 mm Weight: 7.400 kg
used
spindle diameter: 105 mm x-travel: 1250 mm y-travel: 1000 mm z-travel: 600 mm table length: 1100 mm table width: 900 mm tool adaptor: 50 ISO / MK total power requirement: kW weight of the machine ca.: t CNC Table Borer, Reconditioned 2002, BOSCH CC 300 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
spindle diameter: 130 mm x-travel: 7700 mm y-travel: 1500 mm Control: Siemens type: Sinumerik 840 C spindle taper ISO: 130 turning speeds: 1490 U/min power capacity: 45 kW chip conveyor: Angle head: Angle head: Plate area: 9000x6000 mm workpiece weight: 100 t One direction thrust bearing: total power requirement: kW dimensions of the machine ca.: m Panel is optional and we charged extra The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
new
tool clamping area: SK50 mm weight: 1 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
spindle diameter: 120 mm x-travel: 1800 mm y-travel: 1300 mm z-travel: 1500 mm taper ISO: 50 Table dimensions: 1120x1400 mm number of spindle speeds: 0-1.000 total power requirement: 13,2 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
spindle diameter: 160 mm x-travel: 10.000 mm y-travel: 3.000 mm Control: total power requirement: 120/63 spindel kW weight of the machine ca.: 63 t dimensions of the machine ca.: 15x3.85x7.36 m Stocknumber 1210057 Type of machine CNC Floortype boring machine Make WOTAN Type Rapid 5C Build in 2004 Type of control HEIDENHAIN iTNC 530 Spindle diameter 160 mm X-stroke (mm) 10.000 Y-stroke (mm) 3.800 Z-stroke (mm) 700 W-stroke 700 mm Tool Taper Iso 50 Speeds (Rpm) 1,25 - 1250 Feeds (mm/R) 1 - 5000 mm/min Rapid feeds 5 mtr/min. Total Power (KW) 120 /spindel 83 Lenght (mm) 14.500 Width (mm) 3.850 Height (mm) 7.360 Weight 62.300 kg Additional information completely overhould in 2004 and retrofitted by Dorries Scharmann with CNC control HEIDENHAIN iTNC 530 - 4 different angular milling heads - hydrostatic spindle bearing - aerostatic guideways - coolant device - chip conveyo ...
used
internal diameter: 20/300 mm grinding depth: 250 mm swing diameter: 250 mm workpiece spindle - bore: 45 mm workpiece spindle swivable +/-: 25 ° taper setting angle of the workpiece column: 50 ° work piece spindle speed: 42 - 400 U/min grinding spindle speed: 10.000 U/min table speed -stepless-: 0,1 - 8 m/min grinding spindle drive: 4 kW power capacity: 10 kW weight of the machine ca.: 4.500 kg dimensions of the machine ca.: m : : : : : Internal grinding Æ, min./max. 20 / 300 mm Grinding depth 500 mm Table stroke, min./max. 5 / 800 mm Height of centres above table 250 mm Swing Æ in the table recess 600 mm Workspindle bore 62 / 45 mm Swivability of workpiece wheelhead 25 ° Max. taper angle which can be ground 50 ° Infeed, per stroke 0.0025 - 0.5 mm Worksp ...
