used
- Round tube steel DM 6 – 42 x 5 mm - Round tube stainless steel DM 6 – 42 x 3 mm - Pipe push-on length max. 6,000 mm - Programmable logic controller up to 20 angles - Digital display of longitudinal displacement - Digital display of torsion - Programmable, anticipatory mandrel retraction - Mandrel lubrication system by hand pump - Wrinkle smoother receptacle - Bending speed max. 13°/sec - Bending angle up to 180° + 10° deflection - Manual feed - Manual twisting - Right bending direction - Radii from 1.5 D - Incl. bending tool : - DM 12 mm - radius 36 mm ) / DM 15 mm - radius 37.5 mm - DM 18 mm - radius 36 mm - DM 22 mm, radius 44 mm with mandrel - DM 42 mm, radius 44 mm with mandrel
used
Inv. Num. : 5263 Type: DB 642 ST Producer: Transfluid Created: 1999 Parameters: Minimum tube diameter: 6 mm Maximum tube diameter: 42 mm Maximum bending angle: 190 h Machine height: 1150 mm Machine length: 4000 mm Machine width: 650 mm
used
Hydraulic mandrel bending machine with a lot of accessories Preselection of 8 different bending angles with digital display Digital length display as well as digital display of torsion Max. effective length: 6096 mm Round tube steel (S 235): 60.0 x 6.0 mm Round tube stainless steel (S 355): 60.0 x 4.0 mm Square tube steel: 50 x 50 x 4.0 mm Rectangular tube steel: 60 x 40 x 2.0 mm Max. bending angle: 180° Weight: approx. 1800 kg
used
Transfluid EDB 642CNC Tube Bender Year 2020 ROUND TUBING MILD STEEL 1.65" X 0.118" ROUND TUBING STAINLESS STEEL 1.65" X 0.059" MAXIMUM MOMENT OF RESISTANCE 3.4 CM3 (S235) BENDING ANGLE UP TO 180 DEGREES +10 DEGREES SPRING BACK BENDING TIME MAXIMUM 180 DEG./SEC (FRONT FEED) SPEED OF FRONT FEED 1600 MM SEC SPEED OF ROTATION MAXIMUM 450 DEGREE/SECOND REPETITION TOLERANCE BENDING +/-0.05 DEGREES REPETITION TOLERANCE LENGTH +-0.05 MM REPETITION TOLERANCE ROTATION +/-0.05 DEGREES ARBOR LENGTH/USABLE LENGTH 120" RADII MAX. 6.61" BENDING HEIGHT 45.27" BOOSTING FORCE LENGTH POSITIONING 2.5 KN APPROXIMATE DIMENSIONS 296" X 63" X 63" APPROXIMATE WEIGHT 12,100 LBS. EQUIPPED WITH: TRANSFLUID CNC CONTROL WITH WINDOWS 10 OPERATING SYSTEM AND 22" WIDESCREEN MONITOR SERVO ELECTRIC POWER BENDING AXIS SERVO ELECTRIC POSITIONING OF THE ROTATION LENGTH ALL OTHER AXIS SERVO ELECTRIC ...
used
- Pipe diameter 6 - 28 mm - Wall thickness max. 2 mm - Bending radius 2 x D - Bending angle max. 190 - without tools
used
Description Precise forming with quick tool changes. Our axial t form forming machines of type REB are specially suited with forming forces up to 1,300 kN and effortlessly master complex geometries. With up to six forming stages in combination with an intermediate clamping unit, they meet almost all requirements. The operation is simple and intuitive via touch panel. A sequence control makes every single movement of the respective forming stage user-friendly and individually freely programmable. Optionally, we equip our systems with electrical or hydraulic-numerical drives. For very short cycle times, these forming processes can be carried out step by step in transfer plants. The systems enable intuitive flow-based programming. Simultaneous axis movements ensure fast production processes and enable efficient and highly dynamic production. Technical data REB 660 6-60 mm . . .
used
Bending capacity: 6-42mm, connected load: 4kW.
used
Outside diameter maximum: 30 mm Inside diameter maximum: 1 mm Pipe length maximum: 3048 mm Angle degrees maximum: 180 Wall Thickness: 2 mm CNC Brand: _Unknown / Other CNC Model: Transfluid Tube bending machineTransfluid - DB 630 CNC MACH-ID 8531 Make: Transfluid Type: DB 630 CNC Control: Transfluid Year: 1997 Max.Tube Ø 30 mm Min. Tube Ø 4 mm Max. Wall thickness 2 mm Max. Bending radius 180 mm Min. Bending radius 10 mm Max. bending length 3048 mm 3e dimsion bending 360 mm/min. Power 22 kW
used
Electro-hydraulic. Mandrel bending machine make TRANSFLUID type DB 628 ST SPSMasch. -No: 7507/2/2000 year 2000Technical specifications:Pipe diameter 6 - 30 mmMax. Wall thickness 2 mmSolid material up to 20 mmBending radius min. 10 mmBending angle up to 190 °Bending time at 90 ° 3.0 sec.Mandrel length / pipe pushing length 3000 mmRadius range max. 85 mmBending height 1050 mmfreestanding bending head 850 mm lg.Head for clear width between 2 bends of 300 mm distanceNominal pressure 250 barOperating pressure 200 barDrive power 2.2 kWDimensions L x W x H 3500 x 900 x 1300 mmWeight approx 800 kgWith- PLC control, bending process semi-automatic or manually selectable- Storage of 500 tubes with 20 different positions each- hydraulic drive, right-bending- Triggering optionally via foot or hand switch- Bending direction clockwise, hollow shaft for small radii- Tool reset by hand, hydraulic count ...
used
Outside diameter maximum: 50 mm Inside diameter maximum: 6 mm Pipe length maximum: 4500 mm Angle degrees maximum: 0 Wall Thickness: 3 mm Transfluid - DB 648K Tube bender Ø 50 x 4500 mm MACH - ID 6314 Make: Transfluid Type: DB 648K YOP: 1998 Max.Tube Ø 50 mm Min. Tube Ø 6 mm Max. Wall thickness 3 mm Max. Bending radius 125 mm Min. Bending radius 10 mm Max. bending length 4.500 mm Power 1,5 kW Number of tools 2 Dimensions Length 5.600 mm Width 800 mm Height 1.550 mm Weight 700 kg
used
tube diameter: 6 - 28 mm wall strength: 2 mm bending radius min.: 2 x D Control: IPU 20 bending radius max.: 5,0 x D mm bending angle max.: 190 ° arbor length: 3000 mm operating pressure: 180 bar hydraulic motor: 4 kW weight of the machine ca.: 900 kg dimensions of the machine ca.: 3,8 x 1,1 x 1,3 m Condition: ready for operation: Electric 400 Volt: Bending segments: diverse Zoll Bending mandrels: 4 Operation panel: 0,5 x 0,6 x 1,03 m Double Foot pedal: Machine manual: Semi-automatic electro-hydr. mandrel tube bending machine with PLC control for 20 angles and display in the control panel for bending angle specification, angle detection and angle measurement via absolute value encoder, autom. tool plate reset, Turning device with digital display, hydr. quick chuck, aut. Mandrel lubrication, adjustable length stops. Operating modes: manual and semi-automatic. Control buttons: hydraul ...
