Model
(Manufacturer: ROLL)
used
CONTROLS PLC SIEMENS S7 300 SURFACE TREATMENT, USABLE PROCESS SPACE / ZONE length: 7000 mm width: 1040 mm ELECTRICAL SPECIFICATIONS total power consumption: 145 kW mains power supply: 267 kVA mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 7400 mm space requirements -front/back-: 2350 mm total height: 2300 mm total weight approx.: 8000 kg Continuous conveyor belt 1040 mm wide, separated into 3 lines Process:Stage 1: Cleaning (65 degrees)Stage 2,3,4: Rinsing (65, 60, 60 degrees)Stage 5: Heating air drying (60 degrees)Oil separator: continuous oil discharge Heating: electrical heating Convey ...
used
CONTROLS PLC SIEMENS S7 300 SURFACE TREATMENT, USABLE PROCESS SPACE / ZONE length: 9000 mm width: 350 mm ELECTRICAL SPECIFICATIONS total power consumption: 278 kW mains power supply: 450 kVA mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 10300 mm space requirements -front/back-: 2500 mm total height: 2650 mm total weight approx.: 9000 kg 3-lane system with 350 mm usable width each Process sequence: Stage 1: Cleaning (70 degrees) Stage 2,3,4,5: Rinsing (65, 60, 60, 55 degrees) Stage 6: Hot air drying (65 degrees) Oil separator: continuous oil discharge Heating:   ...
used
Multi-chamber diving system make ROLL type RVT 48/32/20/1Komm.-Nr. 3308 built in 1986, with retrofitted drying com. -No: K 3627 built in 1988Basket size L x W x H: 480 x 320 x 200 mmCycle time: according to program, time is preselectedDrying: hot air, negative pressureset temperatures pool ca.:70° CExhaust air volume: 13 cbm / min. at 1800 PaCompressed air consumption: depending on the programCooling water consumption: depending on the program or throughputHeating hot air: 18 kWOperating pressure min.:6 barOperating vacuum approx. 100 mbarTotal connection value including cleaning system K 3308Heating: 46 kW, 70 AMotors: 12.3 kW, 34 A:Dimensions: 3600 x 1800 x 2600 mmWeight approx: 1500 kgWith- Control Siemens S5-115- In 1989 converted to aqueous alkaline detergentsused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by ...
used
Continuous washing plant make ROLL type RWTF0048-032-02-03Machine -No: KO4241, built in 1996Basket size: 500 x 300 x 200 mmMax. Loading weight: 50 kgSmallest cycle time: 5 minutesMedium: tetrachlorethylene (PER)With- autom. feed- Vacuum still and bypass regeneration systemxa0xa0xa0 (Non-stop 24h / day / 365 days / year)- chips cycloneused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
