used
Manufacturer QUASER Model MV204IIU / 10 Year 12/2002 CNC HEIDENHAIN ITNC530 3 Working Tables / Pallets Table 1 Size Ø280 mm. Table 2 Size Ø 500 mm. Table 3 Size 600×400 mm. Max weight allowed on table 265 kg Min-max distance over table 150-760 mm. Axis Longitudinal Traverse (X Axis) 700 mm Cross Traverse (Y Axis 590 mm Vertical Traverse (Z Axis) 480 mm Titling spindle head range (A Axis) ±110º A Axis positioning 0.001º Table turning (C Axis) 360º C Axis positioning 0.001º Rapid Feed (X/Y/Z Axis) 32.000 mm/min Working Feed (X/Y/Z Axis) 15.000 mm./min. Spindle Spindle Speed 10.000 r.p.m. Taper BT-40 Power 15/33 kW Torque 192/189 Nm. ATC ATC Positions 32 ATC system RANDOM Max Tool length 280 mm. Max Tool weight 7 kg Other Equipment Chip Conveyor INCLUDED Internal Coolant 20 Bar INCLUDED Coolnat tank capacity 280 l. Electrical cabinet coolant IN ...
used
Key data: 1230 mm, 560 mm, 530 mm
Tech.Data-Tech. Data X/Y/Z-AXIS-X/Y/Z-axis mm 1230x560x530 Table Size mm 1200x500 Milling Head SK 40, 12000 rpm CNC Control-CNC Control Heidenhain iTNC 530 WZ changer tool changer 30 If you are interested in this machine, please contact us, we will be happy to send you a detailed offer If you are interested in this machine, please contact us and we will be pleased to send you a detailed offer
used
Key data: 1020 mm, 600 mm, 560 mm
Quaser MV 204 II Vertical machining center QUASER MV 204 II with 4th axis Year of construction 2001 Control : CNC control FANUC 18-M Location : Warehouse Hultfred - Sweden Warranty : none Transport : on request Commissioning : on request Specifications X-travel 1020 mm Y-travel: 600 mm Z-travel 560 mm ATC: 32 positions, double arm changer Spindle speed 10000 rpm ISO 40 Spindle motor 15 kW Working feed rate 1-20000 mm/min Rapid traverse 32 m/min Machine dimensions 2200x2650x2830 mm Weight of machine 7500 kgs Other equipment : - NC rotary axis - Tailstock for rotary axis -Conveyor
used
Sell our CNC machine Quaser MV 154 P Travel X700 , Y530, Z500. Spindle speed 12000, 30-fold tool changer SK40 ,IKZ The machine is in very good condition, only plastic has been milled with it. Availability as of now 7000 spindle hours. Spindle re-mounted
used
Key data: 800 mm, 700 mm, 610 mm
Inv. Num. : 7212 Type: MF 630C Producer: Quaser Created: 2015 Parameters: Control system: Siemens 828D Table diameter: 500 mm Number of synchronized axes: 5 pieces Maximum vertical spindle speed: 12000 1/min X-axis travel: 800 mm Y-axis travel: 700 mm Z-axis travel: 610 mm Cone: SK 40 Maximum tool length: 280 mm Workpiece diameter: 630 mm Maximum tool diameter: 76.2 mm Max. tool weight: 7 kg Machine weight: 8750 kg Equipment: Tools Workpiece Probe Renishaw OMP40 ECO Cooler Rinsing gun Rinsing chips from the work area Spiral conveyors
used
Key data: 1000 mm, 530 mm, 560 mm
Quaser MV 154 PL, Control Heidenhain iTNC 530, Year of construction 2008, Travel X/Y/Z 1000/530/560 mm, Tool changer 30 times, Tool holder SK 40, Blowing air through the spindle, IKZ 20 bar, External cooling, Scraper tape chip conveyor, Bkut2g0ceh9 3D touch probe, infrared receiver, Temperature-controlled oil cooling system, thermal compensation, Spindle replacement 2021,
used
Inv. Num. : 7212 Type: MF 630C Producer: Quaser Created: 2015 Parameters: Control system: Siemens 828D Table diameter: 500 mm Number of synchronized axes: 5 pieces Maximum vertical spindle speed: 12000 1/min X-axis travel: 800 mm Y-axis travel: 700 mm Z-axis travel: 610 mm Cone: SK 40 Maximum tool length: 280 mm Workpiece diameter: 630 mm Maximum tool diameter: 76.2 mm Max. tool weight: 7 kg Machine weight: 8750 kg Equipment: Tools Workpiece Probe Renishaw OMP40 ECO Cooler Rinsing gun Rinsing chips from the work area Spiral conveyors
used
Control Heidenhain ... TNC 640 Clamping table surface ... 600mm Axis X ... 885mm Axis Y ... 800mm Axis Z ... 500mm Spindle speed ... 20-12000 rpm. controlled axes ... 5 IKZ ... 20bar ISO 40 Max. workpiece weight ... 500kg Main engine power ... 25kW Rapid traverse ... 36m/min Magazine slots ... 48 Machine weight ... 12100kg L x W x H ... 3800x4050x3200mm The machine is in good condition, possible to test under electricity.
used
Quaser MF 630 five-axis milling machine. CNC control system Siemens 828D Travel in X/Y/Z axis (mm) 800/700/610
used
Machine Details Stock-No. 1105-03857 Type of machine Machining Center - Vertical Make QUASER Type MK 60 II Year of manufacture 1998 Type of control CNC Storage location HAGUENAU FRANCE Country of origin taiwan Delivery time immediately Freight basis EX WORK Technical details X-Travel 1020 mm Y-Travel 610 mm Z-Travel 560 mm tool taper BT 40 spindle drive 25 kW spindle turning speed range 60 - 10000 rpm tool change unit 24-speed BT 40 tool changing time 4 sec table-size 1200 x 635 mm table load capacity - central/maximum 500 kp Rapid Travel X/Y/Z 30 m/min Feeds X/Y/Z -STEPLESS 20000 mm/min total power requirement 40 kVA Additional information CNC control HEIDENHEIN TNC 426 complete covering, A.T.C. for 24 tools BT 40 TABLE 1200 X 635 25 KW 10000 RPM CHIP CONVOYER
used
CNC HORIZONTAL MACHINING CENTER Good condition Control type Fanuc 18I-MB X Axis Stroke 710 mm Y Axis Stroke 610 mm Z Axis Stroke 610 mm Table dimensions 500 x 500 mm Spindle speed 15,000 rpm Spindle connection DIN 6987-1 Permissible weight 500 Kg Tool magazine 60 positions Cooling pressure 50 Bar Table indexing 0,001 Chip Evacuator Accessories
used
Inv. Num. : 6291 Type: MF630/15C Producer: Quaser Generated: 2017 Parameters: Control system: Heidenhain iTNC 640 Number of synchronized axes: 5pcs Minimum vertical spindle speed: 20 1/min Maximum vertical spindle speed: 15000 1/min Travel X-axis: 800 mm Travel Y-axis: 700 mm Travel Z-axis: 610 mm Maximum tool weight: 300 kg Machine height: 2530 mm Machine length: 3710 mm Machine width: 3230 mm Machine weight: 9050 kg Equipment: Workpiece probe Renishaw Jigs Axis X Y Z C A Tools
used
VERTICAL MACHINE CENTER Make : QUASER Model : MK60IIS CNC : Fanuc series 18MC Axis travel: -X (Longitudinal movement of column) = 1020mm -Y (Cross movement column) = 610mm -Z (Vertical movement of spindle head) = 560mm Table: -Table size = 1050x550x2 -Table loading capacity = 300kg x2 Spindle -Max. Spindle speed = 10.000 min^-1 -Type of spindle taper hole = ISO 40/BT40 -Tool storage capacity = 40 [80] Machine size: -Machine height = 3080mm -Floor space (with chip conveyer & 20 bar tank) = 2660x4380mm -Mass of machine = 11500kg
used
Year of construction 2003 Control Heidenhain iTNC 530 Table size 280mm Table load 200kg A-axis +/- 110 degrees B-axis 360 degrees X-axis displacement 700mm Y-axis displacement 590mm Z-axis displacement 480mm Spindle 15000 rpm Rapid passage 32m / min Automatic tool changer Yes, Big Plus spindle system Number of tools32 Tool length 280 mm Tool diameter 88 mm or 125 mm with adjacent pocket area Tool weight 7 kg Input400 / 3 / 50hz 33kW Equipment gap conveyors, coolant, handwheel, oil cooler Features Fully enclosed guarding Length 4000 mm Width 3000mm Height 3000 mm Net weight actually 9,490 kg. / 9.4 tons.
used
Quality unchecked. Please note! Pick-up is only possible by appointment! Rapid feedrate: 36,000mm/min A-axis: +30°~ -120° C-axis: 360° Positions on tool changer: 48 MACHINE CLAMP NOT INCLUDED!
used
x-travel:410 mm y-travel:610 mm z-travel:500 mm turning speeds:15000 1/min tool adaptor:SK 40 control:iTNC 530 HEIDENHAIN smart NC table::320 x 320 mm table load:100 kg tool change unit:48 Pos. total power requirement:35 kVA weight of the machine ca.:7,4 t dimensions of the machine ca.:4,15 x 3,8 x 3,28 m 5-axis simultaneously machining center, NC-round-swivelling table, C-axis 360°, B-axis +30/-120°, chipconveyor, 3D touchprobe, internal coolant supply 20bar, el. handwheel, kinematicsopt, meter readings: approx. 9.600h "machine on", approx.3.500h "spindle on"
used
x-travel:1.500 mm y-travel:700 mm z-travel:610 mm control:HEIDENHAIN iTNC 530 table-size:1.400 x 700 mm tool taper:SK 40 numbers of positions in the tool changer:48 fach spindle turning speed - stepless:15000 1/min rapid traverse:36 m/min table load capacity:700 kg spindle drive:25 kW total power requirement:30 kVA weight of the machine ca.:9,1 t dimensions of the machine ca.:3,7 x 2,65 x 2,9 m vertical machining center, 20 bar internal coolant supply with paper filter, 3D-touchprobe, chipconveyor, el. handwheel meter readings: approx. 43.600 h "machine on", approx. 20.000 h "spindle on",
used
Quality unchecked. A-axis: +30° ~ -120° C-axis: 360° Positions on exchanger: 30 Equipped with Hexagon probe
used
Quaser MV154APC/F12 CNC Vertical Machining Center Fanuc control unit X : 700 mm Y : 530 mm Z : 560 mm Double Table - size is 800 mm x 500 mm Machine is in good working condition
used
Quaser MV154EL CNC Vertical Machining Center X : 1020 mm Y : 530 mm Z : 560 mm Machine can be seen in working condition
used
travel -x axis: 760 mm travel -y axis: 640 mm travel -z axis: 760 mm surface area: 500 x 500 mm control: FANUC Oi-MD numbers of positions in the tool changer: 60 Milling machining centers - horizontal | QUASER - HX504 AE The machine is in a well-maintained condition. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: HX504AE | HX 504 AE | HX-504 AE | HX 504AE The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
This Quaser UX600/15C Vertical Machining Center was manufactured in the year 2015 in Taiwan. It is a 5 axis machine with direct measurement on all axis operated by a Heidenhain iTNC 530 control. With SK40 and 15000 rpm it is the ideal solution for sophisticated simultaneaous machining.
used
This Quaser MF 630C Vertical Machining center was manufactured in the year 2015 in Taiwain and has 4761 production hours. It is equipped with a SIEMENS Sinumerik 828D control unit and has 5 axis. The machine has a spindle speed of 12000 rpm.
used
This Quaser MK603HPD Horizontal Machining Center from 2004 was built in Taiwan. It is equipped with a Fanuc Series 18I-MB control unit. This 4 axis machine can work with a spindle speed up to 15000 rpm.
used
This Quaser MK603SP/12B Vertical Machining center was manufactured in the year 2011 in Taiwan. It is equipped with a Fanuc 18i-MB control unit and has 3 axis. The machine has a spindle speed of 12000 rpm.
used
Control Fanuc 18 i MB X-axis stroke 1020 mm Y-axis travel 500 mm z-axis travel 500 mm table clamping surface 1200 x 500 mm SK 40 spindle support Spindle speed - continuously variable 40 - 12,000 rpm. Spindle motor 18.5 kW feeds 0 - 20.000 mm/min rapid traverse 40 m/min Tool changer 30 Pos FANUC numerical control Machine weight about 6850 kg Machine dimensions L x W x H 2.47 x 2.54 x 2.83 m Intervention on the motor and X axis screw
used
Quaser MK 60 S cnc machining centre in very good condition Fanuc rotopallett board sizes: 2 x 800 mm x 500 mm Strokes: x: 610 mm y: 510 mm z: 510 mm Spindle speed: 80 – 8,000 rpm. Cone: ISO 40 High pressure / internal cooling of the spindle Tool magazine: 30 positions Chip conveyor Complete with documentation
used
Table: 900x500 mm Max weight on table: 500 kgs X-axis traverse: 760 mm Y-axis traverse: 530 mm Z-axis traverse: 560 mm Spindle taper: BT-40 Speed: 12,000 r.p.m. Spindle power: 25 KVA Rapid traverse (X): 40.000 mm/min Rapid traverse (Y, Z): 36.000 mm/min Approximate machine weight: 6.400 Kgs Machine dimensions: 2360x2200x2750 mm Year: 2006 Equipped with: Control: FANUC 18i-MB Tool Changer: RANDOM 24 tools Internal coolant supply: 20 Bar Chip conveyor: Yes
used
used
Quaser MV204 C CNC Vertical Machining Center Machine is in excellent condition Mitsubishi control unit 12 000 rpm spindle speed
