used
Drilling Ø 15/18 mm Table size: 220 x 285 mm Projection: 215 mm Spindle speeds: 480 - 3800 rpm Operating voltage: 380 V Total power requirement: 0.55 kW Dimensions: 930 x 700 x 1770 mm Weight: 128 kg
used
Drilling capacity steel/GG: 23 mm Spindle holder: 3 MK Projection: 275 mm Table size: 300 x 400 mm Quill stroke: 90 mm Spindle speeds: 100 - 1180 rpm Feeds: 0.1/0.6/0.25 mm Drive motor: 380 V, 1.25/2.15 kW Dimensions: 850 x 400 x 1770 mm Weight: 280 kg
used
Offer 22683 Specifications: - Drilling capacity in steel ST 60 35 mm - Drilling spindle holder MK 3 - Drilling spindle stroke 150 mm - 12 drilling spindle speeds in 2 steps 80 - 1400 rpm - Projection 280 mm - max. distance table - drilling spindle 760 mm - Table with 2 T-slots 550 x 400 mm - Height adjustable via rack and pinion with hand crank - Drive 380 V / 1.4 / 2.3 kW - Space requirement approx. W 550 x H 1950 x D 850 mm - Weight approx. 360 kg - with: - Machine vice -Chuck - 10 pcs div drill bits
used
Inv. Num. : 6540 Type: IA 1 TL Producer: IXION Created: 2006 Parameters: Work table length: 700 mm Work table width: 500 mm Control system: Siemens Equipment: Drill bits (150x) Control system: Siemens Work table length: 700 mm Work table width: 500 mm Maximum table load (uniform): 1000 kg X-axis travel: 600 mm Y-axis travel: 400 mm Z-axis travel: 1000 mm W-axis travel: 250 mm Cone: SK 40 Equipment: Swivel work table Leadership assignments High-pressure oil cooling (100 bar) Accessories
used
Specifications: Drilling movement 1000 mm Manual travel : Y = 400 mm X = 700 mm W = 1400 mm Table surface 1200 x 600 mm Table rotatable +/- 180° Adapter SK 40
Max Drilling diameter : 46 mm Max Drilling depth: 1000 mm Table dimensions: 1200 x 700 mm x mm Spindle speed 4000 rpm Spindle power: 7.5 kw
used
Offer 23318 Specifications: - Drilling capacity 28 mm - Drill spindle holder with tightening thread MK 3 - Tightening thread M 12 - Tapping device up to M 20 - Drilling spindle speeds in 2 steps infinitely variable 80 - 1400 rpm - Drilling unit manually height-adjustable - Smallest / largest distance table / milling spindle 170 / 840 mm - Drilling spindle stroke 100 mm - Drilling spindle projection 260 mm - Coordinate table with 3 T-slots 600 x 240 mm - Table travel X-axis / Y-axis 350 / 160 mm - Coolant device - Drive 400 V / 0.7 / 1.3 kW - Space requirement approx. W 800 x H 1650 to 2300 x D 1000 mm - Weight approx. 550 kg
used
Machine Details Warehouse number 1105-03722 Machine type Deep hole drilling machine Make IXION Type TL 500 SVA Year of construction 1985 Control type CNC Control CNC Bosch Alpha Storage location HAGUENAU Country of origin GERMANY Delivery time immediately Freight base from stock Technical details Core drilling diameter - max. 1.5 - 18 mm Drilling depth 600 mm Clamping table, rigid 700 x 1,350 mm Clamping surface of the rotary table 1,000 x 500 mm Longitudinal movement of the table 600 mm Table displacement in drilling direction 400 mm Table rotatable 180 ° Vertical adjustment of the drill carriage 250 mm Drilling unit swivel +/- 15 ° Spindle cone MK 3 Number of speeds 8 Speed range 240 - 2,400 rpm Control CNC Bosch Alpha Motor power 1.0 / 1.6 kW Total power requirement 10 kVA Machine weight approx. 1.35 t Space requirement approx. 2.0 x 1.5 x 1.8 m Infor ...
used
4 axis deep hole drilling machine Brand: Ixion mod. TL1400 Year: 1996/1997 Mitsubishi M530 H control system Executions and Racing Sleeve TL 604 (Z) 600 mm. Sleeve TL 1004 (Z) 1000 mm. Operating unit for vertical drill (standard) (Y) 400 mm. Operating unit for vertical drill (option) (Y) 800 mm. Cross table (table surface 1375 mm. X 700 mm.) (X) 700 mm. Cross table (table surface 1675 mm. X 700 mm.) (X) 1000 mm. Mobile column in the boring direction (W) 1100 mm. Circular table (option) (B) 360 ° Work table Table surface (standard) 1375 mm. X 700 mm. Table surface (optional) 1675 mm. X 700 mm. Load on the table max 2000 kg. Bridge Tool SK 40 holder according to DIN 69871 Tightening bolts according to DIN 69872 Main spindle AC drive (3.0 kW) at 100% of the insertion ratio, S1 3.0 Kw 50% of the duty cycle, S6 5.5 kW Spindle speeds directly programmable 100- ...
used
Tool holder: MK 2 Drilling capacity: 18 mm Speed range, infinitely variable: 200 - 3600 rpm Spindle stroke: 95 mm Table size: 310 x 220 mm Outreach: 215 mm Column diameter: 75 mm Engine power: 0.55 / 1.1 kW Connection: 380 V / 16 A Weight: 95 kg Dimensions LxWxH, approx.: 700 x 450 x 880 mm Facilities: - Stepless speed adjustment - Drilling depth stop - Speed display - Drilling chuck Albrecht 3-16 mm Note: The column sinks into the table.
used
High performance column boring machine Technical data: - Drilling capacity in steel ST 60 32 mm - Thread cutting device up to M 20 - Drilling spindle holder MK 3 - Feeds 0.1 + 0.2 + 0.3 mm/U - Drilling spindle stroke 150 mm - 12 drilling spindle speeds 80 - 1400 rpm - Extension 280 mm - max distance table - drilling spindle 760 mm - Table with 2 T-slots 550 x 400 mm - Height adjustable via rack with hand crank - Drive 400 V / 1.4 / 2.3 kW - Space requirement approx. W 550 x H 1950 x D 850 mm - Weight approx. 360 kg - with: - coolant device - Quick-release drilling chuck - 20 pcs. HSS div. Drill 8 - 25 mm
used
Digital display Heidenhain Thread cutting device Automatic pinole feed Electr. adjustable head (height) Coolant pump Table size 600 x 250 mm Recording MK 3 Speed Continuous
used
Technical data: -Drilling capacity approx. 30 mm - spindle mount MT 3 -Spindle speeds in 2 steps continuously variable 80-1400 RPM -Table surface 390 x 420 mm -Drill unit by hand crank height adjustment -min / max distance table / spindle 220 / 580 mm -Drilling spindle stroke 150 mm -Spindle projection powered 280 mm â 400 V / 1.3 / 2.3 kW -Space requirement approx. B 480 x H 880 - H 1200 X 1050 mm -Weight approx. 250 kg -Table base with storage space B 600 x h. 910 x H 800 mm -Weight 200 kg
used
Table drilling machine Ixion without base from a training workshop Type BT15STP stepless speed control via PIV gearbox Hoehen adjustment via rack, Speeds from 200rpm to 3,600rpm Flott Alzmetall Maxion Gillardon Special price
used
Drilling capacity: 32mm, threat cutting: M5-M20, with 1x IXION BST 23G, 2x REMA HB 15 and 1x IXION BST 15.
used
with motor Stromag: Type. BZFM 063, Power: 0.4 kW
bore capacity in steel (diameter): 13 mm throat: 175 mm bore stroke: 60 mm turning speeds: 480 - 4000 U/min : 230 x 220 mm total power requirement: 1,0/ 400 kW / Volt tool taper: 2 weight of the machine ca.: 90 Kg dimensions: 0,5 x 0.3 x 0,85 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
bore capacity in steel (diameter): 3 - 16 mm : max. 1500 mm weight: 300 kg Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Description: Table dimensions: approx. 170 x 170 mm Approx. Onsite Dimension. (l x w x h): 600 x 260 x 730 mm, weight approx.: 50 kg
used
Description: Machine number 101976 Approx. Onsite Dimension. (l x w x h): 700 x 500 x 900 mm, weight approx.: 150 kg
used
bore capacity in steel (diameter): 40 mm throat: 300 mm bore stroke: 170 mm turning speeds: 70 - 1400 U/min : 600 x 450 mm total power requirement: 3,0 KW tool taper: MK 4 feed: 0,1 - 0,2 - 0,3 mm/U weight of the machine ca.: 320 Kg dimensions: 0,8 x 1,2 x 2,15 mm Column drill - Feed - Left/right rotation - Coolant pump - Vario speed The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
x-travel: 600 mm y-travel: 400 mm z-travel: 650 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC control Heidenhain TNC 415 With 4. Axis (NC-dividing head) 24-fold tool changer coolant device Technische Daten / technical details: X-Weg / X-travel 600 mm Y-Weg / Y-travel 400 mm Z-Weg / Z-travel 650 mm Spindelaufnahme / spindle taper SK40 Tischaufspannfläche / table clamping area 800x400 mm Werkzeugwechselmagazinplätze / number of tools in changer 24 Gewicht ca. / weight 4100 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
table surface area: 170 x 170 mm base plate surface area: 170 x 170 mm throat: 185 mm quill stroke: 65 mm spindle turning speed range: 500 / 896 / 1473 / 2428 U/min column diameter: 65 mm total power requirement: 0,37 kW The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Column drilling machine IXION type BS 30 Masch. No. 00120669 Year of construction approx. 1995 Drilling capacity 30 mm Adapter MK 3 - short quill Projection 260 mm Quoil stroke 120 mm Table size 500 x 350 mm Column diameter 110 mm Spindle speed Level 1 80 - 140 - 230 - 380 - 700 rpm Spindle speed level 2 160 - 280 - 460 - 760 - 1400 rpm. Motor power approx. 1.1 and 2.0 kW pole-switchable Mains connection 380 volts, 50 Hz - Spindle speed over 2 motor speeds and 5 V-belt steps - Table height adjustment via hand crank - quick-release chuck RÖHM Supra 3 -16 mm Space requirement L x W x H 800 x 520 x 1880 mm Weight 230 kg very good condition; used
used
Bench drill, bench drill, column drill, pillar drill -Manufacturer: Ixion, bench drill type BT 6 -Clamping table: 290 x 225 mm -Travel: 150 mm -Spindle mount: drill chuck -Projection: 180 mm -Speeds: 1080 - 12000 rpm 8 levels -Column: diameter 75 mm -Spindle stroke: 60 mm, with fine stop -Motor: AEG 0.37 / 0.6 kW -Voltage: 380V -Dimensions: 640/330 / H740 mm -Weight: 92 kg
used
Drill, column drill, column drill, column drill, tapping machine, box column drill, tapping machine -Manufacturer: IXION, tapping machine tapping machine type BT 15 GLV -Equipment: with lead cartridge -Motor: 0.65kW -Speeds: 320 - 1600 rpm -Table size: 285 x 220 mm, travel 240 mm -Spindle mount: MK2 -Spindle stroke: 70 mm - Projection: 200 mm -Columns O: 75 mm -Dimensions: 680/440/H1460 mm -Weight: 133 kg
used
bore capacity in steel (diameter): 32,0 mm bore capacity in cast iron: 36,0 mm throat: 280 mm bore stroke: 150 mm turning speeds: 120 - 1600 U/min table-size: 400 x 550 mm morse taper: MK 3 feed: 0,1-0,2-0,3 mm/U total power requirement: 1,5 kW weight of the machine ca.: 350 kg range L-W-H: 800 x 600 x 1900 mm Furnishing : - Column drilling machine - Drive: V-belt - continuous speed adjustment via VARIO drive” - automatic spindle feed (0.1/0.2/0.3 mm/rev) - Work table with T-slots - Height adjustable via hand crank - adjustable drilling depth stop with mm scale - Coolant device with container - Connection cable + 16A plug Machine link: https://mhp.logotech.de/hpm/v7/Datenblatt/datenblatt.php?machineno=100 8-9103740 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
bore capacity in steel (diameter): 32,0 mm bore capacity in cast iron: 36,0 mm throat: 280 mm bore stroke: 150 mm turning speeds: 80 - 1400 U/min table-size: 400 x 550 mm morse taper: MK 3 feed: 0,1-0,2-0,3 mm/U total power requirement: 1,1 / 2,0 kW weight of the machine ca.: 350 kg range L-W-H: 800 x 600 x 1900 mm Furnishing : - Column drilling machine - Drive: V-belt - automatic spindle feed (0.1/0.2/0.3 mm/rev) - Pole-changing drive motor - Work table with T-slots - Height adjustable via hand crank - machined base plate with T-slots - adjustable drilling depth stop - Connection cable + 16A plug Machine link: https://mhp.logotech.de/hpm/v7/Datenblatt/datenblatt.php?machineno=100 8-9103736 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Ixion CNC deep hole drilling machine Machine can be seen in working condition Machine is in good working condition Control Unit: Mitsubishi M 530 X axis: 700mm Y axis : 400 (800 optional) mm Z axis : 1000mm W axis: 1100 mm Table size: 1375 x 700 mm Table weight 2000 kg Tool holder: SK 40 Spndle speed: 100 - 4000 rpm. Spindle engine: 3/5,5 kW Drilling capacity: 25 mm
used
Ixion TL1004 CNC Deep Hole Boring Machine Machine is in good condition Tools will be given together with machine(Value is around 9000 EUR) Control Unit: Mitsubishi Meldas X1500 Y700 Z1000 W1000 Table: 360 Degree Drilling capacity 1000 mm Drilling capacity steel à 6 - 32 mm Drilling capacity cast iron à 6 - 46 mm Tapping M M 35 Spindle taper Mk ISO 40 Spindle travel 1000 mm Floor / table area 1500 x 700 mm Power 12.5 kW Spindle speeds / ranges 4500 Rpm DIMENSIONS Length 4000 mm Width 6600 mm Height 2300 mm
