used
Hartford HCMC Vertical Machining Center - 18 :::SPECIFICATIONS::: CNC Model: Fanuc - Tool Holder: ISO 50 - Spindle Power: 20Kw - Spindle Speed: 6000 - Number of Tools: 40 X-axis stroke: 1800mm - Y-axis stroke: 920mm - Z-axis stroke: 700mm - X-Y Z linear axis rapid feeds: 15m/min Table size: 2000 x 920mm Table capacity: 3000Kg Guides: flat High refrigerant pressure: yes Chip conveyor: belt conveyor :::D DIMENSIONS AND WEIGHT::: Length: 6470mm Width: 5290mm
used
HARTFORD LG1000 LG1000 F1 series TABLE Working area mm 1150x510 Table with T-slots mm 18x3x160 Table capacity kg 700 SHIFTS AXIS X mm 1000 Y AXIS mm 510 AXIS Z mm 630 Spindle axis distance to table surface mm 100 ~ 730 Distance of the table axis tip from the column mm 562.5 POSITIONING ACCURACY Positioning accuracy (JIS B6338) mm ± 0.008 Repeatability (JIS B6338) mm ± 0.002 FEEDS Working feed m / min 12 Rapid traverse X / Y / Z m / min 30/30/24 (optional 40/40/32) SPINDLE # 40BT Spindle Nose Spindle speed (belt gear) rpm 8000 (opt. 10000/12000) Spindle speed (DDS) rpm 10000 (opt. 12000/15000) Spindle drive (30 min) 11 kW, belt drive AUTOMATIC TOOL CHANGER Tool magazine capacity A: 24 (opt S: 20) Max. tool weight kg 7 Max. tool dimensions (diameter x length) mm ø75 x 300L (option S: ø90 x 250L) Type of hand ...
used
Machine Details Warehouse number 1105-03571 Machine Type Machining Center - Vertical HARTFORD brand Type VMC 1020 Year of construction 1999 Control type CNC Control FANUC OMD Storage location FRANCE Country of origin Taiwan Delivery time immediately Freight base EX WORK Technical details x-travel 1020 mm y-travel 510 mm z-travel 510 mm Table clamping surface 1200 x 600 mm Speed range - milling 8000 rpm Control FANUC OMD Drive power - Milling spindle 11 kW Tool holder BT 40 Number of tool magazine slots 24 stations Feed range 1 - 10000 mm/min Rapid traverses: 20 m/min Total power requirement 25 kW Machine weight approx. 5500 kg Space requirement approx. 2300x2200x2600 mm Accessories Full protection - fairing Complete machine documentation Information very nice MACHINE CONTROL FANUC O MD SPINDLE BT 40 8000 RPM
used
Machine Details Warehouse number 1105-03546 Machine Type Machining Center - Vertical HARTFORD brand Type VMC 1230 Year of construction 2000 Control type CNC Control FANUC 18 M Storage location HAGUENAU Country of origin Taiwan Delivery time immediately Freight base EX WORK Technical details x-travel 1230 mm y-travel 610 mm z-travel 610 mm Table clamping surface 1400 X 610 mm Speed range - milling 60 - 8000 rpm Control FANUC 18 M Drive power - Milling spindle 11 kW Tool holder BT 40 Number of tool magazine slots 30 stations Feed range 1 - 10000 mm/min Rapid traverses: 20 m/min Total power requirement 25 kW Machine weight approx. 9800 kg Space requirement approx. 3300x2700x2600 mm Accessories Full protection - fairing Complete machine documentation Central lubrication RS 232 - Data Interface Information very nice only working in aluminium CONTROL FAN ...
used
Machine Details Warehouse number 1105-03498 Machine Type Machining Center - Vertical HARTFORD brand Type VMC 1020 Year of construction 2001 Control type CNC Control heidenhein 410 Storage location HAGUENAU Country of origin Taiwan Delivery time immediately Freight base from stock HAGUENAU FRANCE Technical details x-travel 1020 mm y-travel 510 mm z-travel 510 mm Table clamping surface 1200 x 600 mm Speed range - milling 60 - 8000 rpm Control heidenhein 410 Drive power - Milling spindle 11 kW Tool holder BT 40 Number of tool magazine slots 20 stations Feed range 1 - 10000 mm/min Rapid traverses: 20 m/min Total power requirement 25 kW Machine weight approx. 5500 kg Space requirement approx. 2300x2200x2600 mm Information very nice MACHINE CONTROL heidenhain tnc 410
used
Machine Details Warehouse number 1105-03462 Machine Type Machining Center - Vertical HARTFORD brand Type VMC 1020 Year of construction 1999 Control type CNC Control FANUC OMD Storage location FRANCE Country of origin Taiwan Delivery time immediately Freight base EX WORK Technical details x-displacement 1020 mm y-way 510 mm z-path 510 mm Table clamping surface 1200 x 600 mm Speed range - milling 8000 rpm Control FANUC OMD Drive power - Milling spindle 11 kW Tool holder BT 40 Number of tool magazine slots 20 stations Feed range 1 - 10000 mm/min Rapid passages: 20 m/min Total power requirement 25 kW Machine weight approx. 5500 kg Space requirement approx. 2300x2200x2600 mm Accessories Full protection - fairing Complete machine documentation Information very nice MACHINE CONTROL FANUC O MD SPINDLE BT 40 8000 RPM All prices excl. VAT..
used
Inv. Num: 5441 Type: HSA - 428EA Producer: Hartford Generated: 2015 Parameters: Control system: Heidenhain 530iHSCI Working table length: 4000 mm Working table width: 2500 mm Maximum table load (even): 6000 kg Number of synchronized axes: 5 pieces Mechanical feed length Axis X: 4000 mm Mechanical feed length Axis Y: 2000 mm Mechanical feed length Axis Z: 1500 mm equipment: Technical documentation Conveyor Handwheel cube Spindle head Spindle extension Screw sticks (2 pieces)
used
Machining center vertical S - plus 10 Manufacturer: Hartford BJ: 2016 Control Heidenhain ... TNC 640 Clamping table area ... 1150x520mm Axis X ... 1020mm Axis Y ... 520mm Axis Z ... 550mm Spindle speed ... 12000-_/min. controlled axes... 3 cooling ... 20bar ISO 40 Magazine places... 24 chip Conveyor Workpiece probe The machine is in good condition, possible to test under power.
used
Hartford PRO 1000 A machining center The article has been checked for function, the technical condition is perfect. Optical wear exist, the exact state of the article can be found in the article images. Qk0270k Workspace: X 1,020 mm, y axis 520 mm, Z axis 550 mm Accessories and details: HEIDENHAIN control iTNC 530 Ceramic bearing spindle 12000 RPM. Coolant d. spindle (20 bar) HEIDENHAIN Handwheel 24 - specialized magazine Vises and tools do not belong to the auction/scope of delivery! If you are seriously interested, appointments are welcome. Interested parties are always welcome. If you have questions, I am like available.
used
Description: table load: max. 2,500 kg z-motion: 500 mm, x-motion: 2.000 mm, y-motion: 1.200 mm, control: Mitsubishi Meldas control (G-code programmable), table surface area l x w : 2.100 x 1.200 mm, taper: ISO 50, toolchanger positions: 20, power capacity - spindle: 15 kW, turning speed range: 50 - 4.000 rpm, weight approx.: 21,000 kg, Approx. Onsite Dimension. (l x w x h): 5.400 x 3.000 x 3.200 mm
used
This 3-Axis vertical machine center was manufactured in 2000, offering a robust solution for machining tasks. With dimensions of 5500mm x 3851mm x 3408mm, it boasts a sizable working surface of 2100mm x 1050mm. The spindle speed of 6000 rpm ensures efficient operations, supported by a spindle taper of BT50. This HARTFORD HV-80A presents a compelling opportunity for machining projects. For further details, please contact us.
used
Hartford Double Column Machining Center X Y Z : 2000x1500x800 BT50 Mitsubishi control unit 6000 rpm Hartford
used
Machining center Hartford S - plus 10 is in very good technical condition, it is possible to see it in operation. Other informations: - control system Heidenhain TNC640 +15 LcD - Co-04 spindle cooling - cooling nozzles around the spindle - spindle blow through the air - oil separator (standard type - container form) - centralized automatic lubrication system - chip conveyor - manual - OMP60 optical workpiece probe included Manufacturer HARTFORD Machine type S - plus 10 Year of production 2016 Basic parameters 1150 x 520 mm Technical parameters: Table clamping surface: 1150 x 520 mm Longitudinal table movement - x axis: 1020 mm Transversal table movement - y axis: 520 mm Table vertical movement - z-axis: 550 mm Spindle taper: 40 Spindle speed: 12000 rpm Seating capacity: 24 pcs Max. workpiece weight: 700 kg distance from spindle end to table center :: 100-650mm ...
used
This HARTFORD MVP-11 3-axis Vertical Machining Centre was manufactured in 2018 in Taiwan. It is equipped with a 12000 rpm spindle with BT40 tool taper. The automatic tool changer has 24 slots and can process a max. tool weight of 6 kg, a max. tool size of diameter 75 mm and 300 mm length (random tool selection). This 3-axis machine (X = 1200 mm / Y = 600 mm / Z = 630 mm) has a working surface of 1060 x 600 mm with 5 t-slots of 10mm (100 mm pitch) and max. table load of 800 kg. The machine is still under power. Contact us at any time if you have further questions!
used
This HARTFORD PRO 1000 (2011) Machining centers (vertical) machine was manufactured in 2011 . It is equipped with a CNC Fanuc control unit and has 5 axis. It is in very good working condition and can be inspected at any time and disposes a set of 50 tools holders.
used
This HARTFORD HEP - 3150 (2013) vertical machine center was made in the year 2013. It is equipped with a Mitsubishi Steering control unit. The machine has a spindle speed of 10000 rpm.
used
Hartford HB2190S CNC Bridge Type Double Column Vertical Machining Center Machine is in good working condition Mitsubishi control unit X axis : 2000mm Y axis: 1970mm Z axis 920mm Tool holders are included Spindle cooling unit
used
ISO 50 tool holder Spindle power 20 Kw Number of spindle revolutions 6000 Number of tools 40 X Axis Travel 1800 mm Y Axis travel 920 mm Z Axis travel 700 mm XYZ linear axis rapid feeds 15 m/min Table dimensions 2000 x 920 mm Table capacity 3000 kg Flat guides High refrigerant pressure yes Belt chip conveyor
used
Table surface: 1150x600 mm Authorized table weight: 700 kg X/Y/Z travel: 1050x600x630 mm Distance between spindle nose and table surface: 100/730 mm Spindle taper: ISO 40 Spindle motor power 11 kW Spindle speed 8000 rpm 2-speed gearbox Rapid feed speeds 20 m/min Random selection tool magazine: 24 positions CNC FANUC HARTROL AI100 4th integral axis + 5th axis 90°/° positioning GOLDENSUN Spindle center coolant Chip conveyor BLUM IC56 3D infra-red part scanner Full documentation Very good condition
used
x-travel: 3000 mm y-travel: 1970 mm z-travel: 920 mm Control: Fanuc 18 M column daylight: 2200 mm tool taper: 50 spindle turning speed - stepless: 40-4.000 U/min table-size: 3100x1830 mm toolpiece magazine: chain magazine: 40 Stück drive of main spindle: 22 kW total power requirement: kW weight of the machine ca.: 32 t dimensions of the machine ca.: 9,7x6x4,7 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Hartford VMC-560 Vertical Machining Center Machine is in good working condition X: 580 mm Y : 450 mm Z : 480 mm
used
Hartford VMC-1270A Vertical Machining Center X : 1270 mm Y : 635 mm Z : 635 mm Machine is in good working condition All maintenance has been done
used
Machine has been installed in 2006 Table size : 3200x2200mm Machine is in good working condition
used
Hartford Omikron 1020 cnc vertical machining center Number of working hours is very low Machine is in good condition
used
Hartford HV-80S X: 2060 - Y: 1000 - Z: 660 mm CNC X-axis: 2060 mm Y-axis: 1000 mm Z-axis: 660 mm Table dimensions: 2100 x 1050 mm Admission in spindle (ISO): ISO50 Power on the spindle: 25 kW Control : Meldas Toolchanger: yes Number of toolholders: 20 positions Number of rotations: 40 > 4000 rpm
