used
Machining diameter 500 mm max. turning diameter 660 mm Workpiece length 300 mm ----------------------------------------------- Working axes Total stroke X-axis 1180 mm Working stroke X-axis 370 mm Working stroke z-axis 400 mm ------------------------------------------------ Electrospindle Spindle speed up to 1600 1/min Max. power 46 KW Max. torque 2517 Nm CNC control Siemens 840D Driven tool stations Coolant system Conveyor Air extraction system
used
VERTICAL LATHE FAMAR MODEL: ERGO 210 YEAR: 1995 SERIAL NUMBER: FAMAR NR. 95/12 MAX MACHINABLE DIAMETER 200 MM LENGTH OF WORKPIECE MAX MACHINABLE 150 MM X-AXIS STROKE: 340 MM Z-AXIS STROKE: 215 MM FAST AT 60 M/MIN ASA CHUCK NOSE 6 " SPEED: 6000 RPM
used
Nr. 02 VERTICAL LATHES FAMAR MODEL: ERGO 230 SERIAL NUMBER: FAMAR NR. 20.09/1-20.09/2 SWITCHABLE Ø: 250 MM SWITCHABLE HEIGHT: 125 MM Ø SELF-CENTERING: 250 MM SPINDLE ATTACHMENT: 6 ASA ROTATIONAL SPEED: 6000 RPM TOOLHOLDER STATIONS: NR. 12 MOTORABLE: NR. 12. CONTROL: SIEMENS 810
used
X-travel: 180mm, z-travel: 430mm, max. chuck diameter: 160mm, weight: 10t.
used
Available from 01.08.2024
used
Description: CNC control SIEMENS SINUMERIK 840D Workspace Standard chuck diameter [mm] 500 Max chuck diameter [mm] 630 Nominal turning diameter [mm] 450 Max turning diameter [mm] 660 Max swing diameter [mm] 660 Max rotation length [mm] 300 Axle drive Total stroke X-axis [mm] 1180 Working stroke X-axis [mm] 370 Total stroke Z axis [mm] 400 Speed X axis [m/min] 50 Speed Z axis [m/min] 45 X-axis ball screw diameter [mm] 50 Z-axis ball screw diameter [mm] 50 X-axis feed force [kN] 7 Z-axis feed force [kN] 9.4 S3-25% X-axis feed [kN] 22.2 S3-25% Z-axis feed [kN] 25.1 ELECTRIC SPINDLE Spindle nose [ASA] 11 Front bearing ø [mm] 170 Rated power [kW] 28.8 Nominal torque [Nm] 550 Maximum power [kW] 36 Max torque[Nm] 783 Maximum speed [Around] 3200 Powered tool revolver Serrage tools [VDI] 50 Tool quantity [N°] 12 Maximum power [kW] 22.4 Max torque[Nm] 145 Maximum speed [Around] 8000/10000 Max to ...
used
SIEMENS control Machinable workpiece diameter 320 mm Max. workpiece length 180 mm Self-centering spindle 350 mm Spindle attachment nose 8-ASA Speed 0-4500 rpm Power 50 Kw X-axis travel 1000 mm Z axis stroke 2800 mm X axis rapid speed 60 m/min Y-axis rapid speed 30 m/min Automatic loading/unloading time 6-10 sec. Dimensions L x W x H 3580 x 4760 x 2850 mm Weight 12,000 kg
used
sheet width: 1050 mm plate thickness: 5,0 mm pre-bending: 4,0 mm diameter of upper rolls: 110 mm diameter of lower rolls: 115 mm speed: ca. 6,0 m/min work height max.: 890 mm voltage: 400 V total power requirement: 1,1 kW weight of the machine ca.: 1700 kg range L-W-H: 2100 x 550 x 1050 mm Furnishing: - robust electric three-roller drive - asymmetrical roller arrangement - Electrical delivery of the rear/side roller Can be moved via electric button with analogue position display - free-moving operation Clockwise / counterclockwise rotation of the rollers - Manually swing-out top roller - Conical rounding by tilting the rear/side roller - manual delivery of the bottom roller by handwheel - Central lubrication Machinevideo : https://www.youtube.com/watch?v=0JfDoxa7aLM The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
This used 3-Axis lathe manufactured in 2011 features a FANUC SERIES 21I-TB control, with a max. turning diameter of 250 mm and tools type VDI40. It supports X-axis movement up to 340 mm at 90m/min and Z-axis up to 215 mm at 60m/min. The Famar Pronto 6s dimensions are 2715x4275x2558 mm, and it weighs 10,000 kg. This precision and robustness make the Famar Pronto 6 machine we have for sale ideal for high-performance machining tasks. For more details, please contact us to explore this opportunity further.
used
This Famar Tandem 200 Vertical Lathe was manufactured in the year 2010 in Italy. It is equipped with a SIEMENS 840 D control unit. The machine has a spindle speed of 6000 rpm.
used
This Famar Tandem 200 Vertical Lathe was manufactured in the year 2012 in Italy. It is equipped with a SIEMENS 840 D control unit. The machine has a spindle speed of 6000 rpm.
used
3 roller rounding machine from the company Famar 3 x 2550mm rolls Ø 150mm year of construction 1996 traces of use available Equipment as far as known - rope safety switch - emergency stop - Digital display Data sheet and operating instructions unfortunately no longer available The object of purchase is sold under exclusion of any warranty. Exclusion does not apply to claims for damages arising from grossly negligent or intentional breach of obligations of the seller and for any injury to life, limb and health. Price is net without VAT Collection only - Delivery by forwarding agency on request (costs of forwarding agency to be borne by buyer).
used
Sheet thickness: 10,00 mm Bending length: 2550 mm Number of rolls: 4 Make Famar 10 mm Type QI 418 Year 1999 4 roll hydraulic plate bender Sheet thickness (mm)Tickness = 10 mm Bending length (mm)Pre bend = 8 mm Number of rollsLength = 2.550 mm Roll = 250 / 220 mm incl. top support incl. side support incl. conical bending incl. 3 digital readout Fully hydraulic machine
