used
Key data: 10 t, 300 mm, 510 mm
Table 470x460 , installation height 605
used
Dunkes DNA 2 Pneumatic riveting units Dunkes DNA 2 Pneumatic riveting units 20 kN 0.55 kW More items - new and used - can be found in our shop! International shipping costs on request!
used
Two-hand and foot operation Pressing force: 1000 kN Projection: 380 mm Stroke: 650 mm Distance table/plunger, gr. stroke top, verst. above: 950 mm Ejector with end position damping on both sides Ejector travel: 150 mm Ejector force: 160 kN Pressure piece hardened: Ø 98 mm Table surface: 720 x 630 mm Total weight: 7,400 kg
used
Conductive force: 63 t Projection: 280 mm Table size: 500 x 600 mm Installation height: without straightening bridge 600 mm stroke: 160 mm Tappet speed upwards: 117 mm/s m/min Rotary speed downwards: 42 mm/s m/min Space requirement: 1600 x 700 x 2400 mm Weight: 3900 kg
used
Pressing force: 160 kN Impact stroke: 100 mm Mounting height: 350 mm Hole in the table: 100 mm Pushhole bore: 32 mm Stand passage: 650 mm Table size: 630 x 400 mm Hydraulic pressure: 280 bar electr. Connection: 380 V, 5.5 kW Space requirement: 1550 x 1050 x 2400 mm Weight approx.: 3 t
used
Pressing force 160kN,pull cushion force 63kN,stoesselstroke 300 mm, pull-cushion stroke 150 mm, recessed height 500 mm, table 630x400,Stoessel 300x250,pull cushion flap 350x270,
used
Technical data: -maximum pressing force 40 t -maximum piston stroke 218 mm -Height 410 mm -Projection up to mid slide 280 / 370 mm -Table size 650 x 520 mm -Plunger surface 500 x 400 mm -StöÃ?elboaufnahme DIN 810 50 mm -Work speed max.bis 226kN 39 mm / s -Min. working speed 21 mm / s -Eilabsenkgeschwindigkeit 428 mm / s -Rear hub speed min. / max. 100 / 420 mm / s -Table height above floor 820 mm -Oil quantity approx. 400 ltr -Drive 400 V / 15 kW -Space requirement approx. B 1400 x H 3200 X 2200 mm -Weight approx. 7000 kg -with: - hydr. PIN voltage -Control CNC 50 - separate control panel
used
Crimping force at 12 bar: 8 to Pressure to 4 bar: 4 Table size 280 x 280 mm Height 350 mm RADIUS 160 mm Weight 350 kg W x D x H approx. 0.5 x 0.75 x 2,15 m -Stroke adjustment with fine Skallierung: 0.02 mm -Anti-rotation -pneumatic foot switch
used
Pressing force: 250kN, max. stroke: 160mm, working speed: 30mm, connected load: 4.7kVA, weight: 2.2t.
used
Pressing force: 630kN/63t, operating pressure: 270bar, stroke: 400mm, installation height: 600mm, throat depth: 280mm, oil filling: approx. 650l, weight: approx. 5200kg. Documentation available. On-site inspection is possible.
used
Compressive force: 1650kN/165t, stroke: 316.3mm, installation height: 611.5mm, throat depth: 370mm, table height: 820mm, table dimensions X/Y: 820mm/700mm, ram area X/Y: 700mm/450mm. Weight: approx. 14500kg, operating hours: 27200h. Documentation available. On-site inspection is possible.
used
Press capacity: 250 ton Throat depth: 430 mm Stroke: 300 mm Daylight: 500 mm Table surface area : 1.100 x 850 mm Slide area: 1.100 x 850 Table height over floor: 950 mm Approach speed: 330 mm / sec Working speed: 11 - 30 mm / sec Return speed: 330 mm / sec Die cushion capacity in table: 80 ton Die cushion stroke: 100 mm Ejector in ram: 5 ton Ejector stroke in ram: 75 mm Required power: 40 kW Oil volume: 1.400 l Dimensions L x W x H: 3.200 x 2.500 x 4.250 mm Weight of machine approx.: 25 ton
used
pressure:25 t throat:400 mm stroke:1000 mm distance table/ram, max. stroke up, adjustment up:1100 mm table surface area:620 x 620 mm Hole in the table:80 mm table height over floor:650 mm ram surface:110 mm speed down:300 mm/s speed up:500 mm/s working speed:14 - 85 mm/s oil volume:400 l power requirement:6,0 kW weight:3,8 t dimensions (WxDxH):1,5 x 2,1 x 3,9 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2
used
Pressure:63 t distance between columns:1000 mm stroke:300 mm Distance table/ram, max. stroke up, adjustment up:850 mm table surface area:980 x 500 mm table height above floor:850 mm ram surface:130 mm speed down:400 mm/s speed up:461 mm/s working speed:14 - 97 mm/s power requirement:15,0 kW Weight:5,0 t Dimensions (WxDxH):2,0 x 1,6 x 3,9 m depth stop:mechanical foundation pit:not necessary
used
pressure:100 t distance between columns:770 mm stroke:400 mm distance table/ram, stroke up:800 mm Table area:770 x 900 mm table height above floor:850 mm die cushion pressure in table:40 t die cushion stroke in table:200 mm die cushion area in table:600 x 600 mm side window:600 mm ram surface:770 x 900 mm speed down:62 mm/s speed up:350 mm/s working speed:17,5 mm/s oil volume:700 l power requirement:42,0 kW weight:9,0 t Dimensions (WxDxH):2,6x 2,0 x 3,8 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic
used
pressure:40 t throat:300 mm stroke:630 mm Distance table/ram, stroke up:900 mm Table surface area:620 x 520 mm Hole in the table:150 mm table height over floor:600 mm Ram surface:150 mm Power capacity:15,0 kW Weight:4,5 t Dimensions (WxDxH):1,0 x 1,9 x 3,0 m German Safety: permitted for manual loading:CE-sign
used
pressure:315 t distance between columns:2350 mm distance table/ram, max. stroke up, adjustment up:1200 mm distance between cutting impact cushioning:1600 mm Distance table/ram, stroke up:1200 mm stroke:800 mm table surface area:2060 x 1260 mm table height over floor:750 mm Die cushion pressure in table:100 t Die cushion stroke in table:400 mm die cushion area:1250 x 1000 mm side window:780 mm ram surface:2200 x 1500 mm Capacity of ejector in ram:63 t speed down:500 mm/s speed up:310 / 410 mm/s working speed:20 - 73 mm/s quantity of oil:3900 l power requirement:80,0 + 45,0 kW weight:55,0 t Dimensions (WxDxH):4,6 x 2,7 x 7,2 m Height above floor:6,0 m Height below floor:1,2 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 die cushion in table:hydraulic ejector in ram:hydraulic ram interlocking:hydraulic cutting impact absorption:hydraulic
used
pressure:160 t throat:370 mm stroke:150 mm total power requirement:45 kW weight of the machine ca.:22 t dimensions of the machine ca.:2,75 x 1,85 x x 4,80 m rules for accident prevention:Vorhanden work table::1500 x 700 mm Documents:vorhanden
used
pressure:200 t distance between columns:1650 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1200 mm table surface area:1600 x 1250 mm die cushion capacity:80 t die cushion stroke:300 mm die cushion area:1300 x 900 mm table height over floor:800 mm ram surface:1600 x 1250 mm oil volume:ca. 2000 l power capacity:43,0 kW weight:25,0 t Dimensions (WxDxH):2,9 x 2,3 x 5,8 m height beneath floor:0,85 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20
used
pressure:100 t throat:380 mm stroke:650 mm distance table/ram, max. stroke up, adjustment up:950 mm table surface area:800 x 700 mm hole in the table:200 mm table height over floor:920 mm ram surface:630 x 600 mm speed down:65 mm/s speed up:375 mm/s working speed:17 mm/s oil volume:350 l power requirement:18,5 kW weight:9,0 t Dimensions (WxDxH):1,5 x 2,5 x 4,0 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 §20
used
pressure:160 t distance between columns:880 mm stroke:150 mm distance table/ram, max. stroke up, adjustment up:400 mm table surface area:830 x 1000 mm hole in the table:265 x 365 mm table height over floor:850 mm side window:610 mm ram surface:860 x 1000 mm power requirement:55,0 kW weight:14,7 t Dimensions (WxDxH):2,2 x 2,0 x 4,3 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20 depth stop:motoric adjustable table:motoric foundation pit:not necessary
used
pressure:2,5 t
used
pressure:160 t throat:370 mm stroke:150 mm distance table/ram, max. stroke up, adjustment up:500 mm table surface area:1000 x 700 mm hole in the table:100 mm table height over floor:820 mm ram surface:600 x 520 mm speed down:350 mm/s speed up:350 mm/s working speed:12 - 36 mm/s oil volume:1100 l power requirement:27,0 kW weight:16,5 t dimensions (WxDxH):1,8 x 2,7 x 3,95 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:motoric adjustable
used
pressure: 20 KN table surface area: 400 x 400 mm throat: 200 mm stroke - stepless adjustable: 40 mm total power requirement: 0,75 kW dimensions of the machine ca.: 1,0 x 1,01 x 2,03 m Settings before commissioning: Various settings must be made before commissioning the machine. Speed regulation: The adjustment screw for regulating the speed is located above the power selector on the right-hand side of the machines. Turning to the right reduces the speed. Turning it anti-clockwise increases the speed. The adjusting screw can be secured using the lock nut, i.e. once a speed has been selected, it can be permanently set. Force regulation: The force or pressure is preselected using the handle screw on the right-hand housing wall. Turning to the right means more pressure, turning to the left means less pressure. The set pressure can be read on the pressure gauge (on the head of the machine). T ...
used
Description: Control conventional / Option: new (Siemens S7-1500F) Stroke: 650 mm Installation height (top stroke): 950 mm Table surface: 800 x 700 mm Drop-through opening in the table: 200 mm Table height above floor: 920 mm Plunger surface: 630 x 600 mm Speed down: 65 mm / s Speed up: 375 mm / s Working speed: 17 mm / s Oil volume 350 Max. pressing force: 100 to, throat: 380 mm, table surface area l x w : 800 x 700 mm, total power requirement: 18,5 kW, weight approx.: 9,000 kg, Approx. Onsite Dimension. (l x w x h): 1,500 x 2,500 x 4,000 mm
used
pressure: 160 t stroke: 100 mm table surface area: 800 x 420 mm dayligth: 742 mm rapid drop speed: 150 mm/sec work speed: 0 - 15 mm/sec return speed: 300 mm/sec dimensions: 1700 x 1000 x 1680 mm total power requirement: 17 kW weight of the machine ca.: 5,7 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
pressure: 63 t stroke: 617 mm table surface area: 800 x 550 mm dayligth: 1012 mm throat: 320 mm rapid drop speed: 105 mm/sec work speed: 13 mm/sec return speed: max. 416 mm/sec dimensions of the machine ca.: 1350 x 1950 x 4750 mm total power requirement: 20 kW weight of the machine ca.: 6,5 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Single Stand - Hydraulic Press DUNKES Type HZT 2,5 Masch. Nr. H94-2558 Year of construction 1994 Compressive force 2,5 ton. Projection 180 mm Table surface 420 x 300 mm Diarrhoea opening in the table 60 x 185 mm Ram surface 40 mm Pine bore 20 mm Ram stroke 160 mm Installation height max. 250 mm rapid traverse Down 65 mm /sec. Rapid traverse upwards 160 mm/sec. Working speed 8.3 mm/sec. Table height above corridor 950 mm Hydraulic operating pressure 135 bar Tank capacity hydraulics approx. 100 litres Drive power 1.5 kW Mains connection 400 Volt, 50 Hz - Pressure and displacement cut-off - 2-hand operation on the machine - Stroke counter - UVV 11.064 VGB 7.n.5.2 (for manual insertion work) - 32047 read operating hours Space requirement L x W x H 1100 x 980 x 1950 mm Weight 700 kg very good condition; used
used
material width: 3000 mm material thickness: 0 mm no. of straightening rolls: 0 total power requirement: 22 kW weight of the machine ca.: 14,5 t dimensions of the machine ca.: 7,5 x 2,5 x 2,9 m D U N K E S Hydraulic Straightening System for Flat material and Section Material With Straightening Press ( C-Frame ) Model HR 63/TR 25/ HRW 25 Year 1990 ( H 89-1960 ) ____________________________________________________________ Consisting of: Straightening C-Frame Press, Model HR 63, Pressure 63 to, Stroke of Piston 160 mm, Straightening speed up/down 25/75 mm/s, Daylight 550 mm, Distance to column 620 mm, sensitive Straightening stroke via handlever with turret-stop, Measuring device for accurate straitening via a lightbar Horizontal Straightening Device Model HRW 25, Pressure 25 tons attached on right hand side of vertical Press, straightening stroke 160 mm, straightening speed fwd/bwd 57/1 ...
