paper converting: die cutters used for sale

Qty. 1 Second-hand die cutter with flexo printing press Mfc.: M&M Mediterránea de Maquinaria Type: WRC 98 1150-1600/DISTENCO Built: 1999 Flexo printing press with 3 colours Capacity: 50,000 boxes in 1 shift Input material: cardboard of max. dimensions: 1,150 mm x 1,600 mm Output material: boxes (for pizza) Included in the scope: approximately 15 tools for different sizes of boxes New electronics The complete die cutter with flexo printer will require approximately loading on 2 trucks. The box production process is as follows: Ready-made cardboard formats are inserted into the machine, the machine prints up to 3 colours, cuts the box and sends it on with a conveyor and stacks it.

max. plate width: 80 cmstamp width: 425 mmserial no.: 174 plate punch autoplateThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Kama DigitalCut 58 automatic punching machine with hot foil stamping The machine has faults. Year of manufacture 2014 Art.Nr. PS5992

Size: A4

2003 The cutters Max 106 x 76 cm Max sheet size 760 x 1060 mm Min sheet size: 350 x 400 mm Paper 70g/m2 Solid board (depending on the quality) : up to 2000 g/m2 Corrugated board (depending on the quality) : up to 4 mm Speed: 12.000 sheets/hour Cutting force: max. 250 T Approx. total weight: 30 T Equipped with: Full APT in feeder and delivery Non-stop feeder PowerRegister with Baumüller drives Micro Centerline Quick lock system in stripping station Quick lock system in blanking station Chase loader Easytransfer device Frame changer Antistatic for paper Data management unit Extra side blow system Krifft & Zipsner logistic system Machine got a overhauling from Bobst (power register, cooling, lubrication and logistics for 120.000 EUR) In production Available: immediately Located: Germany

Size: 730 x 1040 mmEquipments:Thickness of material: 0,1 - 2 mmDie-cutting precision: ±0.1 mmMax. speed: 7.500 sheets / hourMax. feeding pile height: 1280 mmMax. pressure: 300 Tons

HEIDELBERG CYLINDER S -Max paper size 54x72 cms. -Serial n. 9041 -Complete with ink unit and rollers -New electric cabin with electronic speed control installed ( Inverter ) -Used for die cutting, 2 frames, all accessories -Excellent conditions

Size: 500 x 750 mmEquipments:Max. pressure: 200 TonsMax. speed: 10.000 sheets / hourThickness of corrugated paper: 80 g / m²Heating temperature: 0 - 199°CHeating zone: 10Max. feeding pile height: 1280 mmDie-cutting precision: ±0.1 mm

RABOLINI IMPERIA D -Manual hand fed die cutter, year 1988, totally refurbished in 2024 -Mechanical clutch converted into Pneumatic air system clutch -Max paper size 85x120 cms. -Timer for the speed control -Four spare frames and one spare plate ( total of 5 frames and 2 plates ), all tools and accessories -Very nice conditions, available immediately -Any test is possible in our warehouse also by videocall

Size: A4

Standard

Max. label dimensions: 2x5.5 inch, max. printing speed: 152/min, weight: 150kg, operational hours counter: 573h.

Universal - Register punch Karl Tränklein - Type.: USM 900 - Year of construction: 1992 - Masch. Product no.: 1745 - Table size: 900 x 600 mm - Insert height: max.- 80 mm - with several punching heads

There are two Domino A400 available, were not used for eight years, with ten printing heads.

automatic calendar punch with non-stop feeder, box delivery with vibrator, various punching tools for calendars, etc.

Speed: 3-90m/min, with documentation.

Heidelberg KS, Year 1958 380x520 mm (14.9x20.5") Standard used for die-cutting Available: at short term

There are 21 identical label printer available.

Heidelberg SBG, age 1963 540x770 mm (21x30") Die-cutting Available: at short term

Bahmüller & Göpfert, • BGM Caseline 16/32, • year: 1988, • 2 colour flexo, • slotter with robot setting, • Rotary punch, • Folding machine with vacuum transport, • Tape adhesive from Neubronner (Tapen), • Stitching machine from Bahmüller (Stitchen), • Counting and alignment station, • Transfer station to the bundling machine, • Signode bundling machine (year 1994), • Automatic palletizing system from Bahmüller, • Material removal, • Max Size: 1675 x 3200mm, with SkipFeed: 2100 x 3200mm, • Palletizing height: 2, • Cliché height: 7.35mm, • year: 1988, • Max Size: 1675 x 3200mm, • Palletizing height: 2, • Cliché height: 7,35mm

WUPA PS 4.1 year 1973 - 2003 refurbished size 800 – 1,120 mm Min. size 360 – 500 mm Min. grip 14 mm weights 100 – 1,000 g/m2 Thickness max. 3 mm pressure 240 t Speed max. 4,000 sheets/h Stripping

Bobst SP 142 ER Year 1981 Max.Size: 1420x1020mm Min.Size: 700500mm Max Speed: 6000sh/h Max. cutting force: 600T center line Without blanking – only separating possible.

-----

Enko ES 1800 ST, Year: 2009, TECHNICAL SPECIFICATION, Suitable for the following materials, Solid board up to 300 g/m², Corrugated and laminated corrugated 0.5 - 12 mm, Cabability specifications, Sheet size ……………………………………………………………� ��…………………… max. 1800 x 1300 mm, min. 800 x 700 mm, Cutting pressure max. (450 t) 4.5, Maximum number of strokes max. 3000 s/h, Dimensions and Weights, Length of machine approx. 6300 mm, Width of machine approx. 3200 mm, Height of machine approx. 2150 mm, Weight of machine aprox. 24 t, Pile height, Feeder max 1200 mm, Delivery max. 1160 mm, Technical Data, Gripper edge margin, adjustable from 10 - 18 mm, Cutting knife height 23.8 mm, Wood front edge 27 mm, Electrical connected load 48 KW, Electrical supply 3 Ph, 400 B.C, 50 Hz, Compressed air required 6 bar (kg/m²)

Register punch Masch-No.: 52757/6 with printer 2 FA-OR. Cutting length 315 mm, depth 4 mm, max. 40 mm. Cutting thickness max. 7 mm. Clamping thickness: 1-9 books, max. 50 mm. Spine length max. 400 mm. min. Book width: without printer min. 4 mm cutting depth, max. book thickness 10 - 88 mm (with printer up to 95 mm). Connection 220V, 50/60 Hz, compressed air 6 bar, max. Speed 120/ min. Various knife sets

Heidelberger Dymatrix 105 CS, Baujahr: 2005, min. Format: 350 x 400 mm,, max. Format: 740 x 1050 mm,, max. Stanzfläche: 740 x 1050 mm,, max. Materialstärke: 2000 g/m2 (Wellpappe bis 4 mm),, Funktionen: Stanzen, Rillen, Perforieren, Prägen, Ausbrechen, Gesamtstunden: 4.765 Stunden, Gesamthübe: 15.890.209

electric (380Volt) register punch with manual block clamping and register punch, bolt-action device for the production of registered handles,

Bobst SP 142 E year: 1978 Max speed: 6500 sh/h Max Size: 1020x1420mm Minimum Size: 500x700mm

Stripping Device, Varioplan System, Mabeg Non-Stop Feeder with Pre-Loader, Non-Stop Delivery, Centerline, Elevated, Sidelays On Operator And Off-Side, Formats: Max. 750x1050mm, Min. 350x400mm, Max. Cardboard Thickness: 1,8mm, Max. Corrugated Cardboard Thickness: 3mm, Speed: 9000 Sheets/Hour

ENKO Year: 2014 Model: EA 2200 STFT Technical Specification of Standard Machine Suitable for the following materials: Solid Board - up to 300gsm Automatic Top Feeder - up to 500 g/m² Corrugated and laminated Corrugated - 0.5 - 12mm Cabability specifications Sheet size: max. 2200 x 1700 mm min. 700s 500mm Cutting pressure: max. 440t Max. number of strokes: max. 2200 s/h Dimensions and Weights Length of machine: approx. 9400mm Width of machine without platform : approx. 3285mm Height of machine: approx. 2815mm Weight of machine: approx. 45t Pile height Delivery with 300mm elevation max.1600mm TechnicalData Gripper edge margin, adjustable from 10 - 18 mm Cutting knife height: 23.8 mm, Year: 2014, model: EA 2200 STFT, Cutting pressure: max. 440t
