subcategories
(3rd category level)
Manufacturer:
(Category: 402)
used
PFM SWIFT packaging machine manufactured in 1995, performs the automatic process of packaging various types of products in foil packaging. The reliable and very easy-to-use machine takes the film from a reel above the working area, that is then accurately measured, appropriately cut and cold or hot sealed. At the very end of the process, a special device punches a EUROSLOT hole in the packaging. The packaging machine tooling does not need to be changed when changing the dimensions of the packs. The SWIFT packaging machine weighs 380 kg. Technical data of the PFM SWIFT packaging machine - packing material type: single or multilayer thermo-weldable materials (propylene cellulose film, coextruded film etc.) or PVC - sealing type: elongated profile, spacing 2x 90° - capacity: 60 packs/min - device for making EUROSLOT holes - unloading conveyor - power: 3.2 kW - power supply: 380 V ...
used
Number of sixpack formats: 4, output: 60-70 half-pallets/ h, with infeed and outfeed, turning station, empty pallet magazine, palletiser and PET-transport.
used
KAWASAKI 3RS050N-BC02 palletizing robot built in 2018, is designed to increase the productivity of production lines in many industries by automating the process of palletising products. This 6-axis packaging robot features a compact design with a sturdy arm and a long reach, guaranteeing fast handling of goods weighing a maximum of 50 kg. The total weight of the machine is 555 kg. Technical specifications of the KAWASAKI 3RS050N-BC02 industrial robot - number of axes: 6 - arm reach: 2100 mm - maximum payload: 50 kg - axis movement range JT1 axis: ± 180° JT2 axis: + 140° / -105° JT3 axis: + 135° / -155° JT4 axis: ± 360° JT5 axis: ± 145° JT6 axis: ± 360° - axis motion speed JT1 axis: 180°/s JT2 axis: 180°/s JT3 axis: 185°/s JT4 axis: 260°/s JT5 axis: 260°/s JT6 axis: 360°/s - repeatability: ± 0.06 mm - mounting: floor, ceiling - power requirement: ...
used
With documentation, the machine was only in operation for a few hours, has adjustable shoulders and matching format parts, an on-site inspection is possible.
used
KAWASAKI 3CP180L-AC03 palletizing robot manufactured in 2018, increases the productivity of production lines in many industries by automating the process of palletising products. This extremely reliable KAWASAKI CP180L packaging robot is distinguished by its short cycle times, wide movement range and 4 dynamic axes with high axial speeds necessary to quickly move goods with a total weight of 180 kg. Outside the working area of the machine there is a convenient and easy-to-use controller, whose high funcionality allows the robot to be used comprehensively in the production process. The KAWASAKI industrial robot weighs 1600 kg. Technical specifications of the KAWASAKI 3CP180L-AC03 robot - number of axes: 4 - arm reach: 3255 mm - maximum payload: 180 kg - palletising capacity: approx. 1800 cycles/hour - axis movement range JT1 axis: ± 160° JT2 axis: +95° / -46° JT3 axis: +15 ...
used
Output: 17000 cups/h, running direction: lengthwise. Product: Round cup, with/without snap-on lid: ⌀95mm, cup height: 50mm-120mm. Container dimension: 1. 4 x 3 crates: 395mm x 293mm x 32mm glued. 2.4 x 3 crates: 395mm x 293mm x 51mm glued. 3. 4 x 2 risers: 395mm x 196mm x 31mm glued. 4. 4 x 2 crates: 395mm x 196mm x 31mm glued. Binding cycle times: 4 x 3 crates: 2.54sec. 4 x 2 crates: 1.69sec. Packing scheme: 4 x 2/4 x 3 cups.
used
VEAGOO MACHINE VT-210X packaging machine was manufactured in 2020 in China. Characterised by its simple operation and reliability, the machine is designed for packing products i.e. disposable gloves or masks in bags made of various types of plastic. Highly efficient operation is achieved thanks to the used components and technology, saving time and materials. The VT-210X packaging line automatically determines the cutting length of the bags, then packs them with products with a maximum height of 85 mm, and at the end seals the pack very carefully. Depending on the size of the product being packed, the packaging machine is capable of producing up to a maximum of 150 bags per minute. The packaging machine is equipped with, among others, a PANASONIC PLC control and a YATAI temperature controller. The total weight of the machine is 650 kg. Technical specifications of the VEAGOO MACHINE ...
used
Working width: 3200mm. Available from June, 2024.
used
Hoba CL-HBB Holly Mini Pack semi automatic simple clipband; product packaging is done manually; capacity: 30 bags / min; power: ca 0, 4 kW, 400 V, 50 Hz; printer
used
Cartoner, make Mohrbach, type MB PCT, year 2015, Possible folding box formats:, 92 82 95mm and 92 82 75mm, Function description, Machine for erecting and gluing boxes of flat blanks, as well as filling the boxes, lid molds and lid closing., The magazine supply for the cardboard blanks is monitored by 2 photocells. One is used to warn, at minimum cutting and the second, the machine switches to malfunction when only a few are left, There are blanks in the magazine., A cardboard blank is removed from the inclined magazine by means of a vacuum feeder, into which, Transport guide rails stored and with feed bars horizontally over the folding tool, transported. Here, the blank passes the glue station, where hot glue is applied to the cardboard blank, is applied., After the blank has been transported over the folding tool, it becomes vertical from the, working push-in ram pushed through the ...
used
Ipeka packaging machine with 2 bag blowers used
used
Tevopharm P6 horizontal packer: - height between knives lower and upper jaw: 20 mm - knife width: 100 mm - spacing between the feet on the feeder: 107 mm - productivity up to 220 pcs/min.
used
The CL-35 is a fast, easy to use and compact bagging machine with good ergonomics. packaging machine electrically powered; compressed air (6 bar); product packaging is done manually; bag dimensions: maximum length 500 mm, maximum width 270 mm; performance up to 40 bags / min; engine power ca 0, 4 kW, 400 V, 50 Hz; printer
used
Used BOSSAR B-1400/PH Horizontal Single Dose Packing Machine
used
Hoba CL-HBB Holly Mini Pack semi automatic simple clipband; product packaging is done manually; capacity: 30 bags / min; power: ca 0, 4 kW, 400 V, 50 Hz; printer
used
Specifications Manufacturer CAM Model ASB38 Cellophane wraper bander and TRM HEAT TUNNEL Year 2005 Condition Used
used
For sale is a Somic Wraparound Packer (without lid), which can preferably pack flow-wrap products or thermoformed packs in a wraparound carton by means of two fan conveyors (i.e. two different format sizes and interchangeable format parts). The flat blank is inserted into a magazine and placed on the vacuum belt by means of two suction arms. It is then driven from station 1 to station 2 by means of a servo motor. Hot melt traces are applied between stations 1 and 2, which are glued to the servo-driven folding stamp and the folding die (which are adjustable) after the products have been retracted from the portal. The filled carton then leaves the Somic at the next work cycle and can be taken over at the outlet. The system also has a levelling belt that can be used to distribute the contents of flowpacks. The height and width of the system can be variably adjusted over a wide range. Due to ...
used
Horizontal flow-wrapping machine Pearl Servo D6133 for packaging chocolates and chocolate bars Dataflex 6230; 32 mm (LH) incl. - TTO Ultra black - Print head cleaning kit - Rotary encoder kit - Counter pressure roller 750mm long - Shaft for counter pressure roller - Universal frame - Language Kit - Clarisoft Ergonomic design: HMI and start/stop buttons have been ergonomically situated to facilitate accessibility. High speed and versatility: Up-to 160 cycles/min. with 2UP and capable of wrapping endless diffrent products in the food and non-food sectors. No mechanical drives: Drive motors are connected directly to the various assemblies. The electrical panel is housed inside the machine frame and protected from the external environment. Compact design, easy cleaning: Thanks to the cantilevered construction and the use of polymer moulded components with graceful radiuses ...
used
The fishing and packing plants have a simple and this stable and torsion-free construction. The machines are characterized by ease of use, flexibility, reliability and low maintenance requirements. The CAMBORIT clip has a capacity of up to 125 packs / min. 1 x 2 bottles can be packed with the CAMBORIT clip. To do this from flat so called "bars" cut to shaped, that get caught under the edge of the bottle. The machine can be operated automatically or manually. Display and operating elements are located on the control panel. All functions are controlled from the control panel and controlled. Errors of the cycle are displayed on the control panel. Action: At the beginning of production the magazine must first cut to be filled. The minimum level is cut to the magazine below, the machine will not turn on. After switching on the machine when existing minimum level of bottles with a capac ...
used
for sale flow-pack 65 evo packaging machine the device has never been used in production, it was used for packaging tests. condition as new, no signs of wear and tear price of new machine 70-80000euro
used
We sell a used stacker of the A & F brand. The size and number of the upgrade are variable adjustable (maximum height is approx. 500 mm). Asking price â?¬1500 not overtaken. Obsolete â?¬3500.-
used
polypropylene film packaging machine with production speed 70 packs / minute
used
Cardboard dimensions L min/max 200/650 mm W min/max 150/450 mm, H min/max 120/500 mm Working height 680 mm, format to be adjusted via hand crank, Folding the 4 floor flaps pneumatic operation 6 bar air Power 5-7 cycles /min - product-dependent
used
used
The unit is suitable to pack blisters in PVC + Aluminum, Aluminum + Aluminum, Polypropylene, PET and PVC, Aclar, COC. All the stations are remarkably easy to access and all the movements are fully visible, so that the line is very easy to clean. This machine is equipped with various safety devices to protect the operator. Product parameters can be recalled from a PC, for a quick and easy format change. Reel unwinder driven by a Brushless motor, with automatic machine stop at reel end. Film splicing table equipped with integrated cutter, and automatic vacuum. Forming station entirely managed by Brushless motors. Self-aligning pre-heating plates, independently motorized. Film positioning driven by Brushless motor. Automatic Pitch adjustment directly from the display. Loader trolley MS170 with a maximum load of 300 kg. Dedicated product feeder and relevant enclosure easily remov ...
used
used
Mozzarella packaging machine with outlet conveyor manufacturer: PFM Italia Type: PV260 1.D Year of construction 1997 Condition: used, dismantled
used
Pamminger Raptor 3000 - Wrap stretcher, Model: Raptor 3000 DBS, Year: 2008, Average performance: 80 pallets/hour, Pallet dimensions:, Max. length: 1400 mm, Max. width: 1400 mm, Max. height: 2200 mm, Pallet weight:, Max. weight: 2000 kg, Machine dimensions:, Total height: 4534 mm, Total width: 3300 mm, Total length: 4350 mm, Total weight: approx. 3000 kg, model: Raptor 3000 DBS, Year: 2008, Average performance: 80 pallets/hour, Max. length: 1400 mm, Max. width: 1400 mm, Max. height: 2200 mm, Max. weight: 2000 kg
equipped with 2 sealing tools for shell format (1): 1.6 (sixfold, vacuum and gas) rectangular – corners rounded. Inside dimensions: each tray 177 x 177 mm (W/L) for tray format (2): 1.7 (sevenfold, vacuum and gas) oval, inner dimensions per tray 90 x 140 mm (W/L) Output: 16 to 21 cycles/minute further shell formats can be retrofitted.
used
Industrial robot for the loading and unloading of pallets with filled and empty bottles in crates., Additional title: Pallet packing and unpacking, Capacity: 3000 Crates/h, Lifting load: 360 kg, Weight: 2400 kg, Formats: Euro-Pallet EUR1, Operation / Control: Hand-held programming device, Features: Clamp fixture; Maintenance-free AC servo-motors
