used
Ref. -No.: 10157 Manufacturer: CARL ZEISS Year of construction: 1997 Type of control: HP 9000 Serie 700 Control: Betriebsystem HP-UX.9.05 Storage location: Halberstadt Country of origin: Deutschland Turntable: 1000x2100 mm Machine weight: 4.800 kg Machine Height: 3050 mm Table height above the floor: 850 mm X-Axis: 850 mm Y-Axis: 1800 mm Z-Axis: 600 mm Further information: Three coordinate measuring machine Microcomputer control X-axis as a longitudinally movable portal Y-axis cross slide in the portal Z-axis as measuring head quill (vertical) Passage between the portal approx. 1,000 / 1080 mm Passage in height approx. 750 mm
used
x-travel: 850 mm y-travel: 1200 mm z-travel: 600 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Universal 3D measuring center, double-column, modern software, many accessories The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
x-travel: 550 mm y-travel: 1200 mm z-travel: 450 mm control: 85er 8bit total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Other Info: CNC Double Coloumn Measuring machine MAKE ZEISS West Germany TYPE UMC 850 S YEAR 1995 DIMENSIONS Length 2400 mm Width 1900 mm Height 3050 mm X Travel : 1.400 Y Travel : 1.200 Z Travel : 600 Distance between column : Vertical daylight : 780 Table length : 2.120 Table width : 1.400 Over all dimensions Length : 2.200 Width : 1.900 Height : 3.030 Weight : 3. ...
used
BRAND: ZEISS YEAR: 2001 MODEL: ECLIPSE APPLICATION TYPE: MEASURING LOCATION: BELGIUM MACHINE TYPE: MEASURING MACHINE AVAILABILITY: IMMEDIATELY Technical Information CONTROL UNIT BRAND: ZEISS
used
This Zeiss Eclipse CNC 07/07/06 Measuring machine was made in 2002 in Germany. It is equipped with a ZEISS U-SOFT Plus, Version 9.05, control.
used
Item No. 1000-79 Measuring machine in moving portal construction Make: Zeiss Type: MC 850 Control: Eight-bit control / control cabinet 92 Software: UMESS / ST Table top in granite Measuring range X = 850 mm Y = 1200 mm Z = 600 mm Measurement uncertainty U1 (1) : 2.5+L/250 U3 (1) : 2.8+L/200 Resolution 0.5μm
used
ZEISS MC 850 X-AXIS STROKE: 850 MM Y-AXIS STROKE: 1200 MM Z-AXIS STROKE: 600 MM WEIGHT APPROSS. 3800 KG DIMENSIONS (W X H X D): 1.6 X 1.56 X 2.95 MM
used
This ZEISS ScanMax Measuring machines machine was manufactured in 2019 in Germany. It has 3 axis.
used
This CARL ZEISS ScanMax G32001-9906-000 measuring machine was built in the year 2007 in Germany.
used
x-travel: 9200 mm y-travel: 1600 mm z-travel: 2400 mm dia. of test piece: mm working area: mm dist. between centers: mm control: ZEISS C 99 total power requirement: kW weight of the machine ca.: 30 t dimensions of the machine ca.: 10 x 3,6 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Two-coordinate measuring instruments ZKM Applications: External measurements - Internal measurements - Bore distance measurements with double image eyepiece Shape tests with reable inserts Angle measurements with angle measurement slot and optical rotary table (2") Male thread measurements Equipment: Spitzenbock - Angle measuring device to the tip trestle (5") - adjustable V-bearing opt.-mechanical probe (measuring lever attachment) - adjustable plant table - incident light illumination Projection device - Rotary table with partial circle Increased optical touch accuracy through the use of inteference lines ZKM 01-150 Measuring range x - 150 mm Measuring range y - 100 mm Scale value 0.1 mm ZKM 01-250 Measuring range x - 250 mm Measuring range y - 100 mm Scale value 0.1 mm possible versions: ...
used
Two-coordinate measuring instruments ZKM Applications: External measurements - Internal measurements - Bore distance measurements with double image eyepiece Shape tests with reable inserts Angle measurements with angle measurement slot and optical rotary table (2") Male thread measurements Equipment: Spitzenbock - Angle measuring device to the tip trestle (5") - adjustable V-bearing opt.-mechanical probe (measuring lever attachment) - adjustable plant table - incident light illumination Projection device - Rotary table with partial circle Increased optical touch accuracy through the use of inteference lines ZKM 01-150 Measuring range x - 150 mm Measuring range y - 100 mm Scale value 0.1 mm ZKM 01-250 Measuring range x - 250 mm Measuring range y - 100 mm Scale value 0.1 mm possible versions: ...
used
Zeiss LM 100 large inspection microscope The microscope has been used in the electronics industry, in the production of touch screens
used
x-travel: 711,2 mm y-travel: 711,2 mm z-travel: 508 mm control: ZEISS C 90 HP The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Mechanic lathe Fabr. VEB CARL ZEISS JENAFabr. -No: 607/84, built in 1984Center height: 150 mm:Circumference diameter over support: 75 mmTip width: 550 mmSpindle bore: 27 mmThread pitches: 0.35 / 0.5 / 0.75 / 1.0 / 1.5 / 2.0Operating voltage / control voltage: 380 V, 220 V, 50 HzRated current of the fuse: 25 AExternal dimensions L x W x H: 1250 x 900 x 1350 mm:With- Underframe- Thread cutting device guide cartridge- large rear shelf made of wood 460 x 990 mm- without tailstockused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Antique Universal Measuring Microscope Fabr. CARL ZEISS JENAbuilt around 1939Craft No. 1191used, in good and functional conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Universal length measuring device Carl Zeiss ULM600 used incl. accessories
used
Carl Zeiss WEMI x=150 mm / y=50 mm Accessories Lens 1.5x Lens 3.0x Lace Buck
used
Carl Zeiss Microscope OPMI 7-D surgical microscope The optical fibre cable must be renewed. a spacer rubber on the eyepiece is missing ( see photo ) Microscope is still functional Delivery to curbside.
used
3-D coordinate measuring machine ZEISS NUMEREX Granite measuring plate, granite measuring plate, measuring table Model No. 3648-18, Serial. No. X-1019, year of construction approx. 1986 Measuring range X = approx. 1250 mm, Y = approx. 900 mm, Z = approx. 400 mm Measuring plate L x W 1525 x 1435 mm Usable area 1525 x 1100 mm Measuring plate thickness 305 mm Passage width in the portal 1100 mm Probe holder 9.5 mm Compressed air connection 6 bar Mains connection 230 Volt, 50 Hz. - Granite plate with steel inserts with internal thread - Axis adjustment with pneumatic sliding guide for X, Y and Z-axis - Plate on base frame with 5 pieces of adjustable feet, 3 pieces support plate for the adjustable feet - Computer and software missing (not available and not included) Space requirement of the measuring machine L x W x H 1600 x 1850 x 2200 mm Weight of the machine approx. 2.8 ton. Plate damage ...
used
x-travel: 3000 mm y-travel: 1200 mm z-travel: 1000 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m • RDS 2.5°x2.5° automatic rotary head • Multi-sensor capability, allowing the use of the following tactile probes working: ZEISS VAST-XXT, Viscan, DTS, LinenScan, RST-P and RENISHAW SP25, TP6, TP20 and TP200. • Calypso software • Machine precision: PE_E=(3.2+L/250)µm. MPE_P = 3.0 µm. MPE_THP=4.0 µm. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Electronics unit CARL ZEISS JENA ZE2A Electronic unit for length dipstick IALK and display unit AE80 used, tested ! Dimensions: 170 x 90 x 86 mm
used
Electronic module, control card ZEISS 608481-9003-701 608481-0303 Spare part for 3D coordinate measuring machine ! used, tested ! Dimensions: 235 x 180 x 15 mm
used
Electronic module, control card ZEISS 608481-9003-702 608481-0303 Spare part for 3D coordinate measuring machine ! used, tested ! Dimensions: 235 x 180 x 15 mm
