used
pressure: 25 t throat: 220 mm stroke: 8-80 mm no. of strokes: 140 Hub/min ram - range of adjustment: 50 mm table surface area: 500x410 mm ram surface: 230x170 mm hole in the table: Ø 150 mm tool hole in ram: Ø 35 mm table height: 900 mm weight of the machine ca.: 3 t dimensions of the machine ca.: BxTxH 1500x1500x2400 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
pressure: 63 t throat: 320 mm stroke: 8-100 mm no. of strokes: 120 Hub/min ram - range of adjustment: 63 mm table surface area: 730x600 mm ram surface: 540x360 mm table height: 850 mm tool hole in ram: Ø40 mm weight of the machine ca.: 5,5 t dimensions of the machine ca.: BxTxH 2000x2000x3000 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Single Stand - Eccentric Press WEINGARTEN Type ERV 40 Masch. No. 537 / 65 Year of construction 1965 Compressive force 40 ton. Projection 230 mm Table size 570 x 470 mm Ram surface 250 x 200 mm Clamping pin bore 40 mm Installation height max. approx. 520 mm Stroke adjustment 8 - 88 mm Ram travel 63 mm Stroke rate 70 strokes per minute Drive power 3 kW Mains connection 380 Volt, 50 Hz - Table height adjustment - Overload protection by crushing plate - Clutch-brake combination by WEINGARTEN Friction threaded coupling - electric 2-hand operation and foot switch - Central lubrication via hand pump Space requirement L x W x H 1600 x 1150 x 2300 mm Weight approx. 2.6 ton.; used
used
Single-column eccentric press WEINGARTEN Type ER 63 Masch. No. 52A / 63 Year of construction 1963 Pressure capacity 63 ton. Projection: 280 mm, table surface: 630 x 530 mm, ram stroke adjustable: 8-100 mm, ram adjustment: 63 mm , stroke rate: 65 strokes / min. Motor power 4 kW Mains connection 380 volts, 50 Hz - Clutch-brake combination by WEINGARTEN friction threaded coupling - Electric stroke release via foot switch - Wheel counterweight - Overload protection by crushing plate - Front crankshafts Support bearing Space requirement L x W x H 1500 x 1100 x 2500 mm Weight 4.5 ton. good condition; used
used
Weingarten Excenter Press
used
Punching machine make WEINGARTEN type XKSHw 30Press force: 30 tSheet thickness: 1.5 mmStrokes per minute: 80 - 240Tappet adjustment: 45 - 20 mmRam stroke: 10 - 60 mmTable size: 300 x 500 mmOpening in the table: 120 x 220 mmDischarge: 170 mmPassage between the columns in front Machine: 400 mmExternal dimensions L x W x H: 1500 x 1400 x 2200 mmWith- Feed device- straightening station- modern control cabinet rear a.d. machineused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Eccentric press make WEINGARTEN type ARV 63Order number. 121101, built in 1971Technical specifications:Pressing force: 63 tgr. sheet thickness: 10 mmDischarge: 270 mmTable: 760 x 480 mmDiarrhea hole in the table: 250 x 150 mmNumber of strokes: 56 and 84 / mingr. distance table - ram: 500 mmkl. Distance table - ram: 200 mmRam stroke: 8 - 100 mmRam adjustment: 63 mmExternal dimensions L x W x H: 900 x 2000 x 2600 mmWeight approx: 4 tonsWith- UVV for inlays- EMERGENCY STOP SWITCHused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
used, well-preserved Müller-Weingarten punching machine HUQ 400.22F, Y.O.M. 2000, pressing force 400 tons, table 2200 x 1300 mm, stroke fixed 150 mm, 30-120 strokes/min variable, with roller feed, straightening machine and feed system for material 450 mm wide, max. sheet thickness 6 mm, ram adjustable 150 mm, installation height 400-540 mm, tool change cart
used
pressure: 160 t no. of strokes: 40 - 120 Hub/min sheet width: mm total power requirement: 40 kW Pressing capacity 160 ton Table clamping area 1,100 x 1,280 mm Ram clamping area 850 x 890 mm Distance between guides 1,120 mm Distance between columns (below guide ways) 1,350 mm Distance between Table and ram in upper position approx. 400 mm No. of strokes 40 - 120 /min Adjustment of stoke 67 / 115 / 160 mm Ram adjustment, motor driven 125 mm Ejector travel 50 mm Total electrical load, approx. 40 kW - 500 V - 50 Hz Weight, approx. 24,000 kg Accessories / Special Features * WEINGARTEN Sheet Metal Uncoiler with overhead loop control (space saving because it does not need a loop-pit). Strip width 375 mm. The loop control guides the strip-material from the uncoiler to the machine thru a straightening device with automatic supervision. * 8-track slide bearing guide. * Automatic oil-circulation l ...
used
Continuous straightening machine make WEINGARTEN type RA 21Machine -No: 141240 built in 1973Technical specifications:Number of reels: 7Roller diameter: 40 mmstepless speed: 10Passage width: 240 mmDrive power: 1.5 kWused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Punching machine make WEINGARTEN type XKSHw 30Fabr. -No: 600/64, year of construction 1964Press force: 30 tSheet thickness: 1.5 mmStrokes per minute: 80 - 240Tappet adjustment: 45 - 20 mmRam stroke: 10 - 60 mmTable size: 300 x 500 mmOpening in the table: 120 x 220 mmDischarge: 170 mmPassage between the columns in front Machine: 400 mmExternal dimensions L x W x H: 1500 x 1400 x 2200 mmWith- Feed device- straightening station- modern control cabinet rear a.d. machineused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Punching machine make WEINGARTEN type XKSHw 30Fabr. -No: 764/59, built in 1959Press force: 30 tSheet thickness: 1.25 mmStrokes: 80 - 240Tappet adjustment: 45 - 20 mmRam stroke: 10 - 50 mmTable size: 300 x 500 mmOpening in the table: 120 x 220 mmDischarge: 170 mmPassage between the columns in front a.d. Machine: 400 mmExternal dimensions L x W x H: 1500 x 1400 x 2200 mmWith- Feed device- straightening station- modern control cabinet rear a.d. machineused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Type / type: N 25 Year of make: 1977 Manufacturer / make: Weingarten Rated pressure: 25 t Number of strokes: 140 / min Radius slide center to frame: 200 mm Window in frame: 240 mm distance table slide: 250 mm Stroke adjustment / adjustment of stroke: 8 ... 80 mm Ram adjustability/adjustment of ram: 50 mm Ram size / surface of ram: 355 x 220 mm Table size / surface of bed: 560x 400 mm Hole in table: 160 mm Power of main motor:3 kW Weight / weight: 2,23 t
used
Ram, rams for an eccentric press, single column press, punching machine, single column eccentric press, eccentric press - single column, press -Spare part: comes from a Weingarten eccentric press -Stroke adjustment: 10-80mm -Plunger area: 320 x 65 mm -Plunger mount: O 40 mm -Plunger adjustment thread: M64 x 6 mm -Plunger adjustment ball head: approx. 92 mm -Dimensions: 875/320/H190 mm -Weight: 164 kg -Pressure unknown
used
Manufacturer: Müller Weingarten Type: S1700.12.33.1 Year of construction: 1982 Total pressing force: 17000 kN Working capacity from 15 strokes/min: 225000 J Max. pressing force per stage: 4000 kN Pressing force cutting ram: 2000 kN Adjustability of cutting ram: 60 mm Cutting ram stroke: 180 mm Pressing force puller 1: 15000 kN Adjustability of drawrod: 100 mm Drawrod stroke: 350 mm Number of tool positions: 13 pcs. Coil strip system consisting of: - Reel AH 13000/600/MSG-4Q - Coil loader wagon LW - Introductory aid Tigro - Precision straightening machine - Belt transfer station - Roller feed - Hydraulic system - Electrical system and control system Location: Mettingen
used
WEINGARTEN ER 100 Eccentric press Capacity 100 t Table 710 x 570 mm Sheet thickness 12 mm Number of strokes 55 spm Ram stroke 8-112 Ram adjustment 80 mm
used
Inv. Num. : 5723 Type: GDK 750 Producer: Weingarten Created: 1987 Parameters: Clamping force: 866 t Plate size: 1280x1280 mm Distance between tie rods: 790x790 mm Tie rod diameter: 165 mm Closing stroke: 850 mm Opening the mold: 400-900 mm Injection force: 73 t Injection positions: 40/170/300 mm Weight: 36000 kg Machine dimensions: 8250x2000x3400 mm Equipment: Krownmatic KM 1200 Oven (2011)
used
sheet width:2000 mm plate thickness:1.8 mm Controls:SIEMENS S7 PRESS DESIGN:. - frame design : H-frame :. - openings in uprights : yes :. - opening in table : yes :. - moving bolster : yes :. PRESS TABLE:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - height above floor level:375 mm RAM:. - ram force:800 to - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - stroke:350 mm - number of strokes max:55 /min RAM (MECHAN. PRESS):. - ram adjustment:350 mm TOOL ASSEMBLY DIMENSIONS:. - shut height (stroke down, adjustment up):1100 mm - distance between columns (H-frame):3100 mm - Free passage between side columns (width):2560 mm - Free passage between side columns (height):1500 mm DECOILER:. - design : single coil :. - sheet width max:2000 mm - sheet width (min):400 mm - max. weight of coil:30 to - max. diamet ...
used
pressure:200 t stroke:30 - 160 mm no. of strokes:40 - 120 /min distance between columns:1500 mm distance between oil collecting pans:1300 mm distance table/ram, max. stroke up, adjustment up:860 mm hole in the table:550 x 300 mm table surface area:1250 x 1250 mm table height over floor:1000 mm column travel -side:600 x 530 mm ram surface:1250 x 1000 mm ram adjustment:125 mm Material width of feeder:30 - 500 mm Material thickness feeder:0,5 - 3,0 mm feeding length:0 - 999,9 mm power requirement:50,0 kW weight:34,0 t dimensions (WxDxH):4,0 x 1,7 x 5,2 m clutch-/ brake combination:pneumatisch, Ortlinghaus overload protection in ram:hydraulisch ram adjustment:automatisch stroke adjustment:automatisch ram counterbalance:pneumatisch roll feed:Weingarten, WE 60 Option: NEW electrical controls:Siemens S7-1500 F
used
Several used machines are available, including 1) a Fritz Werner milling machine, 2) a Weingarten 160 eccentric press, 3) a Schuler 80 eccentric press, 4) a Nilfisk floor cleaning machine, 5) a belt squeegee oiler, 6) a continuous cleaning machine, 7) an Ixion threading machine, 8) push forks, 9) a reel and 10) a continuous heating channel. Some of these machines are defective or damaged.
used
see picture in the appendix
used
pressure: 500 t distance between columns: 1600 mm stroke: 60 mm max. ram stroke: 60 1 / min ram adjustment: 100 mm total power requirement: kW weight of the machine ca.: 40 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
pressure: 80 t throat: 400 mm stroke: 8-112 mm ram adjustment: 80 mm no. of strokes: 52/78 Hub/min table surface area: 750x550 mm ram surface: 400x300 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
pressure: 100 t passage width: . mm stroke: . mm tracking travel: 45 mm safety distance: 208 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
pressure: 63 t distance between columns: 0 mm stroke: 160 mm table surface area: 630 x 500 mm dayligth: 400 mm total power requirement: kW weight of the machine ca.: 5 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
