used MAZAK slant turn

Technical information Swing over bed 420 mm Distance centre tot centre 1000 mm Max longitudinal travel Z-axis 1028 mm Max cross travel X-axis 335 mm Spindle coneA2-6 Dia of spindle bore 56 mm Power on the spindle20/25 hp Number of speeds16 - 4000 rpm CommandMazatrol Cam T3 Total power needed18,5 kW - 32,9 kVa Length 3734 mm Width 1893 mm Height 2401 mm Weight 4400 kg Toolchanger yes Number of tools 16x - rotating yes milling tools C-axis Robo flex automatic loading system tooling included Measuring arm included MAZATROL CAM T-3 CNC Accessories Tailstock, Evoquator, Tool Attachments, Presetting Machine weight 4700 kg Axis C Yes

Machine type: CNC turning center QT Nexus 200-II Manufacturer: Mazak Model: QT200 Built: 2008 Switch-on hours: approx. 27,770 hrs - Food Kitagawa BB 208 - Hollow spindle: 65 mm - max machining diameter: approx. 380 mm - max. rotation length: approx. 538 mm - Travel Z: 575 mm - max speed: 5000 revolutions - Disc turret: 12 stations - Drive power: 26 kW - riding stick, fixed tip - Chip conveyor, Tooleye - incl. 12 tools

Bearing number: 3695 CNC LATHE Manufacturer: Mazak, Type: Quick Turn Nexus 350 MY Year of construction: 2006 Specifications: circulation diameter 420 mm dia. max. rotation. over bed 700 mm dia. Turning length 1538 mm Main engine power 30 kw Main spindle speed range 25-3300 rpm Spindle bore 102 mm dia. C Axis - Haupspindel Movement 0.001 degrees Z Ash Movement 1607 mm Y axis 150 mm Tool turret with 12 stations Powered stations revolver 1 12 pieces. Motor power Driven tools 7.5 Kw Driven werkzeuumdr. 25-4500 rpm Control Mazatrol 640T Nexus Fabr. Accessories: Various tool holders. Tool setter Chip conveying. Hydr. Lunette Length: 4300 mm, Høhe: 2400 mm, Width: 2600 mm, Weight: 8600 kg

Turning-milling center Manafacture: Mazak Type Quick Turn 250 MSY Year of construction: 2017 Switch-on hours approx. 12,000h Cycle hours approx. 8,000h Conveyor High-pressure pump Machine milled 100% only aluminum Features Chuck diameter main spindle 10 " Chuck diameter counter spindle 6 " Max. swing diameter 695 mm Max. turning diameter 380 mm Max. rod diameter main spindle 80 mm Main spindle Max. speed 4,000 min-¹ Rated power (30 min. operation) 26.0 kW Torque (max.) 465.0 Nm Counter spindle speed (max.) 6,000 min-¹ Rated Power (25% DC) 11.0 kW Torque (max.) 90.0 Nm Tool turret Number of tool slots 12 (all positions driven) Milling spindle power (40% DC) 6.0 kW Max. milling spindle speed 5,000 min-¹ Max. milling spindle torque 47 Nm Feed axes rapid traverse X-axis (max.) 30 m/min Rapid traverse Y-axis (max.) 21 m/min Rapid traverse Z-axis (max.) 33 m/min R ...

Key data: 720 mm, 1235 mm, 3300 1/min

Machine Details Stock-No. 1105-03948 Type of machine CNC Turning- and Milling Center Make MAZAK Type Quick Turn Smart 350 Year of manufacture 2012 Type of control CNC Storage location HAGUENAU Country of origin Japan Delivery time immediately Freight basis EXW (Incoterms 2000) loaded on Price Technical details turning diameter 420 mm turning length 1280 mm control MAZATROL SMART Dialog Swing Dia. 720 mm rapid power traverse in X-and Z direction 20 m/min Chucking diameter 250 mm Bar Material Dia. 102 mm Spindle Drive 30 kW Spindle Speed: 3300 spindle nose JIS A2-8 tailstock quill taper MT MK5 Tailstock Quill Stroke 110 mm tailstock quill diameter 100 mm Tailstock Travel 1300 mm total power requirement 50 kVA weight of the machine approx. 7 t dimensions of the machine approx. 4.5x1.7 m Accessories manual tool eye Additional information Machine IN GOOD C ...

Mazak Quick Turn Smart 200L CNC Lathe Machine is installed in 2017 Turning length : 1100 mm Turning diameter : 400 mm

Key data: 535 mm, 190 mm, 4000 1/min

MAZAK QUICK TURN 200 Year of construction.2001 Fodder. 210 mm 8.5 inc Spindle bore. 61 mm Revolver. 8 pieces Engine. 43 kVA Control: MAZATROL 640 T PC-Fusion CNC, Chip conveyor. 8 pieces of tool holders, 4 pieces VIDEOS !! Japan Machine,

Mazak lathe QUICK TURN 40 :::SPECIFICATIONS::: CNC Model: Mazatrol - CNC Version: MAZATROL T-PLUS - Main Spindle Nose: ASA 8 Main spindle power: 30Kw - Main spindle self-centering diameter: 305mm - Main spindle bar passage: 80mm Main spindle speed: 3000 Turning diameter: 400mm Turning Length: 1524mm Number of Tool Turrets: 1 Number of fixed tool positions first turret: 24 Rapid feeds of linear axes X Y Z: 18m/min Tailstock: Yes Chip conveyor: belt conveyor Presetting: yes Self-centering bezel: yes Min diameter - Max diameter: 10 - 200mm :::D DIMENSIONS AND WEIGHT::: Length: 4230mm Width: 1883mm Height: 1885mm Weight: 6200Kg

Tool Revolver 8-speed Mazak Quick Turn 10N Machine used, good condition from assembly of a MAZAK Quick Turn 10N CNC lathe My. 1985 satted with 8 tool-places Turret 290 mm Space requirement LxWxH: 580 x 460 x 380 mm Price is understood plus VAT freely loaded warehouse Casting - shipping possible after arrangement and assumption of costs Changes / errors in the technical data as well as intermediate sale reserved Seller Offer No. resale 8904

Mazak Quick Turn Smart 200 ML CNC Lathe with C Axis Mazatrol Control unit Machine is in good condition

2-axis/16 tools on turret Max diameter: 310mm Max length: 1010mm

Mazak Quick Turn Nexus 150 CNC Lathe Machine is in very good condition 8 inches Length : 500 mm Turning Diameter : 300 mm

Mazak Quick Turn Smart 200M L Cnc Lathe Machine is in good working condition Maximum swing 660 mm Maximum machining diameter 350 mm

Mazak Quick Turn Smart 200 Cnc Lathe Machine is in good working condition Maximum swing 660 mm Maximum machining diameter 350 mm

Complete turning centre, can also be used for long turned parts. Use of standard lengths of 6m for raw materials (bar loader). Machine with double turret, 24 tool positions in total. Machine with double spindle. Machining time 330 hours to date.

turning diameter: 290 mm turning length: 310 mm control: Mazatrol Smooth C swing diameter: 580 mm bar material dia.: 45 mm main spindle speeds:: 5000 U/min main drive motor: 7,5 / 11 kW Torque: 95,5 Nm disc turret: 12 fach travel -x axis: 195 mm travel -z axis: 325 mm traversing speed: 30 m/min tailstock taper MT: MT 4 total power requirement: 26,65 KVA weight of the machine ca.: - t dimensions of the machine ca.: 1,9 x 1,6 x 1,7 m - CNC control Mazatrol Smooth C - Tool turret 12-position - center Tooleye - Tailstock MT4 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This 2-Axis lathe was manufactured in 2000. The MAZAK QUICK TURN 10 features a standard machining diameter of 100mm, a turning length of 256mm, and supports an 8-position tool turret. Key specifications include a main spindle speed of 60-6000 rpm, rapid traverse speeds up to 30.5 m/min (X) and 33 m/min (Z), and a hydraulically operated 3 cam chuck system. Ideal for detailed and precise machining tasks, the MAZAK QUICK TURN 10 machine we have for sale is robust and reliable. For more details, contact us today.

This lathe was manufactured in 1996. With turning diameter of 440 mm and turning length of 451 mm, it offers precise machining capabilities. Controlled by Mazatrol T PLUS, it ensures efficient operation. Equipped with a Kitagawa B208 A6 chuck spinning at 5000rpm, it delivers consistent performance. Tailstock adjustment up to 500 mm enhances versatility. We have this MAZAK Quick Turn 20 machine for sale, representing a valuable opportunity for your machining needs. Contact us for further details.

Description: CNC lathe with feeder Control Mazatrol CAM t-2 Chuck Ø 200 mm Alarm on x-axis weight approx.: 11,000 kg, Approx. Onsite Dimension. (l x w x h): 4,100 x 1,800 x 2,200 mm

Description: Specification : Bed Length 26' Capacity Machine Swing : 29.5' / 760 mm Maximum Machining Diameter : 16.540' / 420 mm Maximum Working Capacity : 4' / 102 mm Maximum Machining Length : 23.8' / 603 mm Main Spindle Chuck Size : Kitagawa 15' Maximum Speed : 4000 rpm Motor Output (30 min rating) : 40 Hp / 30 kW Second Spindle Chuck Size : Kitagawa 10' Maximum Speed : 4000 rpm Motor Output (30 min rating) : 35 Hp / 26 kW Turret (Upper) Number Of Tools : 12 Maximum Speed : 6000 rpm Motor Output (30 min rating) : 10 Hp / 8 kW Feed Axes Travel (X Axis) : 11' / 280 mm Travel (Y Axis) : 6' / 150 mm Travel ((Z Axis) : 26.39' / 670 mm Travel (W Axis) : 26.63' / 650 mm Complete with Turbo Vacummentation SWL 69 kgs Swing Jib Crane, Demag electric lift hoist. turning diameter: 420 mm, Drehlänge: 603 mm, serial number: 325,905, turning diameter over slide: 29.5 ...

Description: MAXIMUM SWING 660 mm - MAXIMUM MACHINING DIAMETER 350 mm - MAXIMUM bar WORK CAPACITY 65 mm - MAXIMUM MACHINING LENGTH 511 mm - CHUCK SIZE 200 mm - MOTOR OUTPUT (30 MINUTES/CONT. ) 15/11 kw - CROMAR S334901 a SWARF CONVEYOR - TOOL PRESETTER ARM - TAILSTOCK x-motion: 190 mm, z-motion: 560 mm, control: Mazatrol, toolchanger positions: 12, weight approx.: 4,410 kg, Approx. Onsite Dimension. (l x w x h): 2,750 x 1,700 x 1,700 mm

MAZAK INTEGREX 200 SY + FLEX GL-100C. 2001. MAZATROL 640 MT control maximum turning diameter 540 mm Z-axis travel 1,065 mm Main spindle maximum RPM 5,000 rpm Main spindle full C-axis Counter-spindle maximum speed 6,000 rpm Y-axis +/-80 mm Milling spindle for turning and milling Spindle maximum speed 6,000 rpm Full B-axis, 225° Tool changer with 40 tool positions KM-63 tool mount Tooleye 1 x 3 - jaw Chuck, diameter 210 mm 1 x 3 - jaw Chuck, diameter 170 mm Gantry loader Flex GL-100 C. High pressure cooling through spindle, 20 bar Chip conveyor CE mark

MAZAK INTEGREX turning/milling center 200Y Bu. 1999 Mazatrol fusion control Max Drehdurchm. 520 mm Max Schwingdurchm. 540 mm Maximum turning length 1,018 mm Bar passage 51 mm C-axis + angetr. Tools Y-axis +/-70 mm Distance between the top 500 mm Drive 30 kW Maximum main spindle spindle speed 5,000 rpm Maximum speed milling spindle 6,000 rpm Tool changer with 40 stations 3-jaw Chuck 200 mm Tool measuring arm Tailstock Chip conveyor Total connected load 31 kVA Machine dimensions 3.50 m x 2.10 m x 2.50 m Machine weight 6,800 kG 25 tool holder KM 36 duty hours approx. 36,000

BRAND: MAZAK YEAR: 2017 MODEL: INTEGREX i-630V/6 APPLICATION TYPE: TURNING LOCATION: ISRAEL MACHINE TYPE: LATHE AVAILABILITY: IMMEDIATELY Technical Information GENERAL DATA MEASUREMENTS WIDTH: 5362 MM MEASUREMENTS DEPTH: 7703 MM MEASUREMENTS HEIGHT: 3813 MM MACHINE WEIGHT: 35000 KG CONTROL UNIT BRAND: MAZAK MODEL: MAZATROL SMOOTHX CNC MAIN DRIVE SPINDLE SPEED RANGE: 10000 1/MIN MOVEMENT X-AXIS MOVEMENT: 1425 MM Y-AXIS MOVEMENT: 1050 MM Z-AXIS MOVEMENT: 1050 MM B-AXIS MOVEMENT: 150º MMC-AXIS MOVEMENT: 360º MM WORKPIECE WORKPIECE DRM OVER BED: 1050 MM WORKPIECE DRM OVER SUPPORT: 1000 MM TABLE OUTER LENGTH: 630 MM OUTER WIDTH: 630 MM Additional Information MACHINE BENEFITS TECHNICAL MACHINE BENEFITS: - MAX. MACHINING DIAMETER: 1050 MM - NUMBER OF PALLETS: 2

BRAND: MAZAK YEAR: 2019 MODEL: INTEGREX I-300 APPLICATION TYPE: TURNING LOCATION: SOUTH KOREA MACHINE TYPE: LATHE AVAILABILITY: IMMEDIATELY Technical Information GENERAL DATA MACHINE WEIGHT: 15700 KG MAIN DRIVE SPINDLE SPEED RANGE: 4000-12000 1/MIN TOOL TAPER: HSK-A63 NUMBER OF AXIS: 5 MOVEMENT X-AXIS MOVEMENT: 615 MM X-AXIS RAPID TRAVERSE: 50 M/MIN Y-AXIS MOVEMENT: 260 MM Y-AXIS RAPID TRAVERSE: 40 M/MIN Z-AXIS MOVEMENT: 1585 MM Z-AXIS RAPID TRAVERSE: 50 M/MIN B-AXIS MOVEMENT: -30º~210º MM Additional Information MACHINE BENEFITS TECHNICAL MACHINE BENEFITS: - MAIN CHUCK SIZE: 254 MM - MAX. SWING ON CARRIAGE:DIA 658 MM - MAX. MACHINING DIA:DIA 658 MM - MAX. MACHINING LENGTH:1519 MM - MAZAK API, ENGRAVING FUNCTION - MTCONNECT ADAPTER, SYNCHRONOUS TAPPING FOR TURNING/MILLING - TOOL RADIUS COMPENSATION / 5-AXIS, ENGRAVING FUNCTION, TOOL CUTTING P ...
