used HACO hsl

This HACO HSL 3013 Shearing machine was manufactured in the year 2007 in Belgium. It is equipped with a HACO SP8 control unit. The machine has a cutting thickness of 13mm

Haco HSL 3100 x 16 mm Cutting length: 3100 mm Max sheet thickness st 45: 16 mm Strokes/min: 5 > 10 str/min Backgauge: 1000 mm Adjustable cuttingedge: 0,5 - 4°30´ Electric motor (power): 37,5 kW Length: 4160 mm Depth: 2220 mm Height: 2450 mm Weight: 15 ton

CNC hydraulic guillotine shears FAbr. HACO HSLX 4010brand newTechnical specifications:Max. Cutting length: 4050 mmMax. Sheet thickness for ST 4 10 mmMax. Sheet thickness VA (1.4301): 6 mmTable height: 1030 mmCutting angle: 0.5 - 3 degreesCutting gap adjustment: 0.05 - 1.0 mmNumber of hold-down devices: 23Back stop area: 1000 mmBackgauge speed: 110 mm / secStroke rate: 7-11Working height: 1030 mmrequired oil filling: 220 litersLength of the angle stop: 1000 mmHolding device option: 7780, -Length of the support surface: 930 mmMax. Sheet thickness: 8 mmMotor power: 18.7 kWOption control panel on the swivel arm: 930.00Machine dimensions: 5150 x 2050 x 2395 mmWeight: 13 tWith- SC 100T controlwith ergonomic control panel - simple operation directly on the cutting table- enables convenient operation ofBackgauge, retraction and cutting length limitation- Electronic cutting gap adjustment - Cutti ...

The machine is in good technical condition, it is possible to test it by agreement. Max. sheet length: 3000 mm Max. sheet thickness: 16 mm Weight approx.: 12000 kg Dimensions: 4200x1700x2300 mm

The machine is in good technical condition, after prior agreement it is possible to test it. Cutting length: 3000 mm. Max. sheet thickness: 16 mm.

The machine is in good technical condition, can be tested under power. Cutting length:3000 mm. Max. sheet thickness: 10 mm.

BRAND: HACO YEAR: 2018 MODEL: HSLX 3006 APPLICATION TYPE: SHEARING LOCATION: SLOVENIA MACHINE TYPE: SHEARING MACHINES AVAILABILITY: IMMEDIATELY Technical Information GENERAL DATA MEASUREMENTS WIDTH: 1750 MM MEASUREMENTS DEPTH: 3800 MM MEASUREMENTS HEIGHT: 1650 MM MACHINE WEIGHT: 5000 KG CONTROL UNIT BRAND: HACO MODEL: SC100 T Additional Information MACHINE BENEFITS TECHNICAL MACHINE BENEFITS: - WORKING WIDTH: 3050 MM - WORKING THICKNESS: 6 MM - MAX. CUTTING ANGLE: 3 MM - ENGINE POWER: 7. 50 KW

SC 70 CNC control: - cutting angle automatic - knife play automatic - backgauge automatic Cutting length: 3100 mm Max sheet thickness st 45: 8 mm Max sheet thickness inox: 4 mm Strokes/min: 11 > 22 str/min Backgauge: CNC - 750 mm Adjustable cuttingedge: 0,5 - 3° Electric motor (power): 11 kW Length: 3950 mm Depth: 1750 mm Height: 1720 mm Weight: 5 ton

Reinforced version, for 3-shift work. CNC SC5 control. The machine automatically sets both the angle and the gap after entering the material thickness. The machine has a quickly changing gap between the knives with CNC-controlled sheet thickness reading, and a hydraulically variable knife angle in the range of 1-3 degrees. 7.5 kW motor. Weight 6 tons. Electric bumpers with CNC position reading and setting, bumper travel 1050 mm. The bumper has a retraction function. Supports to hold sheets of metal at the front of the machine, with a ruler for cutting at an angle of 90 degrees. Original O&M documentation and occupational health and safety manual in Polish. The guillotine cuts sheet metal from 0.8 to 6 mm. The machine is functional, the cutting knives are 90% new.

sheet width: 3050 mm plate thickness: 6,00 mm distance between columns: mm cutting angle: 0,5 - 3,0 ° drive motor: 11 kW down holder: 18 Stück total power requirement: kW weight of the machine ca.: 6,00 t dimensions of the machine ca.: m • Automatic cutting angle adjustment • Automatic cutting gap adjustment • Cutting line lighting • Support arms • Knife with 4 cutting edges • Cutting length limitation • CNC back gauge 705mm adjustment range 705 mm • Angle stop • Operation manual The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 3000 mm, 13 mm

Machine Type: Guillotine Shears Manufacturer: HACO Type: HSLX3013 Year of construction: 1996 Condition: used / good **Offer will only be sent if a complete imprint is provided!** Location Warstein , Germany Reference MV-KÖL-0424-2 DESCRIPTION We offer you a used guillotine shears from the manufacturer HACO. Cutting capacity 3m x 13mm Haco's control system renewed. further data on request. Availability: by arrangement Our offer is aimed at tradespeople who are registered within the meaning of the Trade Regulation Act according to §14 GewO. The offer is subject to change, subject to prior sale. Please provide your full contact details to receive a quote with our terms and conditions and payment terms. Errors in the descriptions and offers are excepted

Hydraulic panel shears - storage machine - incl. foot switch, touch screen, rear installation room with light barrier monitoring, automatic/electric cutting gap, automatic/electric cutting angle, hydraulic hold-down, mot. Backgauge up to 1000 mm depth -Illustrations similar- Hydraulic plate shear - storage machine - incl. foot switch, touchscreen, rear set-up area with light barrier monitoring, automatic/electrical cutting gap, automatic/electrical cutting angle, hydraulic hold-down, mot. backgauge up to 1000 mm -images similar-

Sheet thickness: 6,00 mm void: 0 Table length: 3000 mm Table width: 3000 mm Knife length: 3000 mm MACH-id    5325 MAKE        HACO TYPE          TS 306 YOP            80 er SPECIFICATIONS Guillotine / Lazer / Cutting table        Guillotine Cutting lenght         3050 mm Maximum sheet thickness      6 mm Backgauge stroke X in mm        0 - 1000 mm DIMENSIONS Length       3600 mm Width         2100 mm Height        2000 mm

Specifications: - Cutting length up to approx. 220 mm - Cutting thickness - Steel with 400 N/mm² strength 4 mm - Stainless steel with 600 N/mm² strength 3 mm - Cutting angle 90 ° - Stroke rate up to approx. 35 1/min. - Depth stops left + right - Table support surface 600 x 400 mm - Table height approx. 1000 mm - E – Foot switch - Drive 400 V / 2.2 kW - Space requirement approx. W 800 x H 1200 x D 650 mm - Weight approx. 500 kg

Sheet thickness: 6,00 mm Sheet width: 2000 mm Depth rear gauge: 0 mm Maximum sheet thickness:    6 - 4 mm Max. cutting length:        2.060mm Strokes on full length:     30mm Strokes in short 1000 length:55 Cutting angle:              1,20 ° Length backgauge:           1.000mm Number of down holders:     9 Power:                      7,5 kW Length:                     2.150 mm  Width:                      1.750 mm  Height:                     1.700 mm  Weight:                   ...

Capacity: 320 t Folding length: 4100 mm CNC Brand: _Unknown / Other CNC Model: Robosoft ATS 900 MACH-id     5560 MAKE         HACO belgium TYPE           ERM 40320 YOP             2005 SPECIFICATIONS Max. bending length         4100 mm Distance between column        3150 mm Max. pressing force           320 T Dis. Beam - Table         500 mm Beam stroke                  250 mm Troth beam                     330 mm Approch speed               80 mm/min. Working speed                8 m ...

Sheet thickness: 12,00 mm Sheet width: 3000 mm Depth rear gauge: 1000 mm MACH-id    5484 MAKE         HACO TYPE           HSL 3012 YOP             90 er SPECIFICATIONS Maximum sheet thickness         12 mm Max. cutting length                    3100 mm Strokes on full length                 17 mm Strokes in short 1000 length       21 Cutting angle      0,5 - 3 ° Length backgauge        0 - 1000 mm Number off down holders        18 Approach speed         50 mm/sec. Power          15 kW DIMENSIONS  Length  &n ...

: 6 mm : - t : 4 kW : 250 mm : 90 ° : 35 Hub/min The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Sheet thickness: 13,00 mm void: 0 Table length: 4100 mm Table width: 4100 mm Knife length: 4100 mm MACH-id    5322 MAKE         HACO Belgium TYPE           HSLX 4013 YOP            2000 SPECIFICATIONS Control        Robosoft SC7p Guillotine / Lazer / Cutting table        Guillotine Cutting lenght        4100 mm Maximum sheet thickness        13 mm Backgauge stroke X in mm      0 - 1000 mm DIMENSIONS Length     4300 mm Width       2500 mm Height      2200 mm

Key data: 3100 mm, 6 mm

HACO TS 3006 hydraulic guillotine shears manufactured in Belgium in 2006, are used in manufacturing plants to cut steel sheets with a maximum length of 3100 mm and a thickness of 6 mm. The machine has vertically aligned knives with four cutting edges, which ensure high precision and quality machining of workpieces regardless of the thickness and type of sheet. The angle of the cutting knives and the gap between them are adjusted by means of two levers at the rear of the machine. During machining, the workpiece is pressed against the cam in order to take an accurate measurement on the gauge located between the front stop and the bottom knife. Two parallel hydraulic cylinders drive the cutting bar (the upper knife attached to the slider) to perform the movement in the up-down direction. The HACO guillotine shears are offered with equipment which includes a foot control, a modern HACO SP ...

Sheet thickness: 6,00 mm void: 0 Table length: 0 mm Table width: 0 mm Knife length: 3050 mm MACH-id     5122 MAKE          HACO Belgium TYPE            HSLX YOP              2011 SPECIFICATIONS Control        Cybelec CybTouch 8 Guillotine / Lazer / Cutting table         Guillotine Cutting lenght         3050 mm Maximum sheet thickness       6 mm Backgauge stroke X in mm      750 mm DIMENSIONS Length        3400 mm Width         4000 mm Height        2100 mm

BRAND: HACO YEAR: 2017 MODEL: ERMS30250 APPLICATION TYPE: BENDING LOCATION: CZECH REPUBLIC MACHINE TYPE: BENDING MACHINES AVAILABILITY: 01 12 2023 Technical Information GENERAL DATA MEASUREMENTS WIDTH: 3320 MM MEASUREMENTS DEPTH: 2000 MM MEASUREMENTS HEIGHT: 2750 MM MACHINE WEIGHT: 12900 KG CONTROL UNIT MODEL: EASY BEND 2D MAIN DRIVE PRESSING FORCE: 2500 KN BENDING LENGTH: 3100 MM NUMBER OF AXIS: 4 Additional Information MACHINE BENEFITS TECHNICAL MACHINE BENEFITS: - WORKING STROKE 200 MM - BACKGAUGE STROKE 800 MM - WORK SPEED 8 MM/S - MAIN MOTOR POWER 18. 7 KW - 4 CONTROLLED AXES Y1, Y2, X, R - MANUAL CROWNING (BOMBIERUNG) - INCLUDING TOOLING QUALITATIVE MACHINE BENEFITS: - VERY GOOD CONDITION, LOW HOURS

Sheet thickness: 13,00 mm void: 3050 Table length: 0 mm Table width: 0 mm Knife length: 0 mm SPECIFICATIONS Controll   SC 70 Robosoft Guillotine / Lazer / Cutting table   Hydraulic Guillotine Cutting lenght    3050 mm Maximum sheet thickness  13 mm Backgauge stroke X in mm   0 - 1000 mm DIMENSIONS Length  4300 mm Width   2200 mm Height  2500 mm

electrical network - 380 V frequency – 50 Hz main fuse – 20A main engine directly on line main engine power – 7.5 kW motor with rear pressure gauge – AC 0.37 KW control: SP8 Cutting length - 3100 mm Thickness of cut sheet metal in grade S355 - 6 mm, stainless steel sheet - 4 mm.

sell angle notcher HACO VARI 220X220 variable angle and stainless steel blades like new
