used
x-travel:800 mm y-travel:690 mm z-travel:630 mm total power requirement:76 kW weight of the machine ca.:25,5 t b-axis:630 Rundeinheit control:Siemens 840 D workpiece weight:max . 1.100 kg spindle turning speed range:15000 U/min Boring power:30 mm plate size:630 x 630 mm Dimension:6000 x 2900 x 2400 mm spindle taper::HSK 63 Documents:vorhanden
used
Travel X/Y/Z: 800mm/690mm/630mm, max. spindle speed: 15000 rpm, drilling capacity: 30mm. Table size X/Y: 630mm/630mm, max. workpiece weight: 1100kg, control: Siemens Sinumerik. Dimensions X/Y/Z: 6000mm/2900mm/2400mm, weight: approx. 25000kg. Spare parts available. Including chip conveyor and separate coolant system.
used
BRAND: GROB YEAR: 2011 MODEL: G350 APPLICATION TYPE: MILLING LOCATION: SLOVAKIA MACHINE TYPE: MACHINING CENTERS (UNIVERSAL) AVAILABILITY: 01 08 23 Technical Information CONTROL UNIT BRAND: SIEMENS MODEL: SINUMERIK 840D MAIN DRIVE SPINDLE SPEED RANGE: 18000 1/MIN SPINDLE MOTOR POWER: 29/39 KW MOVEMENT X-AXIS MOVEMENT: 600 MM Y-AXIS MOVEMENT: 770 MM Z-AXIS MOVEMENT: 805 MM TABLE OUTER LENGTH: 400 MM OUTER WIDTH: 400 MM TOOLS SLOTS IN STORAGE: 34 TYPE OF TOOL HOLDER: HSK-A 63 - The machine on offer is a SINGLE Piece of the generation 0 in hydraulic-free execution. - Electromechanical pallet clamping system. - Workpiece carrier pallets with an electromechanical pallet clamping system. - Adjustment device for electromechanical clamping on pallet. - Electromechanical motor spindle. - Second-hand machine, without torque motor in the A axis. - The A-a ...
used
GROB VERTICAL BANDSAW TYPE NS 18 -Uitlading 450 mm -12/600 m/min -Zwenkbare work table -380V DUTCHMACH Metal working machinery ENSCHEDE - NETHERLANDS (3 km from the German border)
used
This GROB G350 Universal Machining Center was manufactured in the year 2011 and has 54019 hours, of which 17507 are spindle hours. It is equipped with a SIEMENS SINUMERIK 840D control unit. The machine has a spindle speed of 18000 rpm.
used
x-travel:800 mm y-travel:950 mm z-travel:1020 mm control:HEIDENHAIN iTNC 530 table load capacity:800 kg tool taper:HSK 63 turning speeds:16.000 1/min spindle:35 / 25 kW table-size:770 mm max. torque on the spindle:160 / 223 Nm tool change unit:120 (2x60) Pos. weight of the machine ca.:20 t dimensions of the machine ca.:3,3 x 6,15 x 3,2 m 5-axis simultaneously machining center with controlled swivel-rotary table (A/B-axis), milling head horizontal, internal coolant device (10-80bar), oilmist-suction, electromech. tool-length measuring device GROB, chipconveyor, 3D touch probe, KINEMATICOPT, BLUM laser, el. handwheel, hour meter: approx. 80.500 h "machine on", approx. 48.500 h "spindle on"
used
Various round-stroke tables with clamping elements, for conversions or adaptations, etc.
used
Various round-stroke tables with clamping elements, for conversions or adaptations, etc.
used
Feed sled unit hydraulic, various spindles, for conversions or adaptations
used
Feed sled unit hydraulic, various spindles, for conversions or adaptations
used
weight of the machine ca.:11,2 t one spindle
used
x-travel: 600 mm y-travel: 855 mm z-travel: 750 mm table surface area: 400 x 400 mm clearance diameter: 720 mm pivoting angle: -185 / +45 Grad workpiece weight: 340 kg table rotation speed: 50 U/min tool taper: HSK-A 63 spindle turning speed - stepless: 12000 U/min spindle motor: 40 kW tool diameter: 70 mm tool length - max.: 365 mm weight of tools max.: 8 kg rapid travel range: 70/45/90 m/min control: Heidenhain iTMC 530 total power requirement: 54 kVA weight of the machine ca.: 15 t dimensions of the machine ca.: 6,1 x 2,47 x 3,17 m The 5-axis universal machining center G350 offers nearly unlimited possibilities in the milling of workpieces of various materials. materials. equipped with: - CNC control Heidenhain iTNC 530 - 2-fold Pallet Changer - NC swivel rotary table (A-/B-axis) - tool changer 40 places (HSK A63) - IKZ / coolant system 3-22,5bar - chip conveyor The data for this ad ...
used
x-travel: 600 mm y-travel: 855 mm z-travel: 750 mm table surface area: 570 mm clearance diameter: 720 mm workpiece weight: 400 kg pivoting angle: -185 / +45 Grad table rotation speed: 50 U/min tool taper: HSK-A 63 spindle turning speed - stepless: 12000 U/min spindle motor: 40 kW tool diameter: 70 mm tool length - max.: 365 mm weight of tools max.: 8 kg rapid travel range: 70/45/90 m/min control: Heidenhain iTMC 530 total power requirement: 47 kVA weight of the machine ca.: 13 t dimensions of the machine ca.: 6,1 x 2,47 x 3,17 m The 5-axis universal machining center G350 offers nearly unlimited possibilities in the milling of workpieces of various materials. materials. equipped with: - CNC control Heidenhain iTNC 530 - NC swivel rotary table (A-/B-axis) - tool changer 40 places (HSK A63) - IKZ / coolant system 3-22,5bar - chip conveyor 2 identic machines available The data for this ad ...
used
5-axis machining center with 2-fold pallet changer Travel x/ y/ z = 600/ 770/ 675 mm Swivel/rotary table (A/B axis) Pallet changer 2-fold Pallet size 400x400 mm Spindle speed up to 16,000 1/min Spindle power 160/ 223 Nm Tool magazine 34-fold + additional magazine 99 tool positions Tool holder HSK 63 - Control Siemens 840D sl - Additional magazine TM99 - Automatic opening/closing for manual loading and unloading - Pallets with fluid connections (coupling connections) - Electromechanical tool length device - Infrared probe Renishaw - Internal coolant supply, infinitely variable up to 38 bar - Handheld control unit - Workspace extraction - Remote machine diagnostics - Brankamp machine protection system - Hydraulic clamping of the workpieces on the pallet
used
pressure: 7 t max. workpiece diameter: 43 mm threading length: 3000 mm swivel angle for work spindle: 10 ° total power requirement: 6,5 kW weight of the machine ca.: 1,280 kg dimensions of the machine ca.: 1,4x1,8,1,4 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
x-travel: 800 mm y-travel: 1020 mm z-travel: 970 mm Control: HEIDENHAIN iTNC 530 : 18000 min/-1 Feeds (X,z,u,w-axis): 29 / 39 kW tool taper: HSK 63 : 60 Pos. rapid travel x/y/z: 65/50/80 mm/min table diameter: 630 x 630 mm table load capacity: 700 kg max. workpiece diameter: 900 mm A-Axis: -185 / +45 ° b-axis: 360 ° total power requirement: 42 kVA weight of the machine ca.: 22 t dimensions of the machine ca.: m 5-axis BAZ Equipped with: - CNC control HEIDENHAIN iTNC 530 - pallet changer 2-fold (630x630mm) - tool changer 60-fold (HSK-A63) - Swivel rotary table (A-/B-axis) - IKZ 4-38 bar - chip conveyor - belt filter system - spindle cooling 6 Machines available The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
x-travel: 750 mm y-travel: 1000 mm z-travel: 870 mm Control: 840 D total power requirement: 29 kW weight of the machine ca.: 22,5 t dimensions of the machine ca.: B 3,2 x L 6 x H 3.3 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
throat: 450 mm Table dimensions: 610 x 610 mm : 3660 x 6 mm total power requirement: 1,5 kW machine weight ab.: 600 kg dimensions: 1150 x 1000 x 1950 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Key data: 800 mm, 1020 mm, 970 mm
coarse G 550 / 5 axles, Year of construction 2016, Control Heidenhain iTNC 530, travels X/Y/Z 800/1020/970, Schuler Automation LMC 900, 15 pallet spaces, Pallet size 600 x 600 mm, Ww 60 speed, Additional magazine 218 seats, HSK 63, Spindle speed up to 16,000 rpm, new spindle Februrar 2024, 2 axes NC swivel rotary table Ø 770 mm, A axis -185° / + 45°, B axis 360°, IKZ, Conveyor Auto. Off and on, 3D Probe Heidenhain, Kinematic Option,
used
Description: Machine no. 218 Control: conventional Workpiece diameter 115 mm Workpiece length 2150 mm Toothing diameter 120 mm Number of teeth - max. 96 Number of teeth - min. 12 Rolling head speed 1,800 rpm Feed rate 30 - 180 mm/min Rapid traverse 1,800 mm/min Total power requirement 20 kW Approx. Onsite Dimension. (l x w x h): 5,700 x 3,000 x 2,300 mm, weight approx.: 11,000 kg
used
x-travel:600 mm y-travel:655 mm z-travel:685 mm weight of the machine ca.:17 t dimensions of the machine ca.:4x3,1x3,1 m
used
x-travel:600 mm y-travel:655 mm z-travel:675 mm weight of the machine ca.:22 t dimensions of the machine ca.:4,0 x 3,20 x 3,20 m 2 spindles, 5 axes B axis 360 x 0.001 Spindle: 20kW each, 12,000 rpm HSK-A63 2 x 40 pos. For technical data see attached PDF Machining center G 320 AB with swivel changer Project: GM 4284/01-01 to 06 Process: Production of cylinder head cover Al Si 9 Cu 3 Minimum quantity lubrication 1-channel Lubrix 2x5bar/4x10bar Lubricant Eccocut Micro Plus20 Tool magazine 2x40, cone cleaning Tool holder HSK 63 tool breakage control Tool monitoring Artis probe BDE connection Control Siemens 840D Solution Line NCU 720.2 (730.2) PN with PLC319-3PN/DP
used
x-travel:750 mm y-travel:800 mm z-travel:865 mm weight of the machine ca.:23 t dimensions of the machine ca.:4,93 x 3,50 x 3,28 m b-axis:360 (0,001) ° with B axis 360 x 0.001 2 spindles (each 29 KW, 12,000 rpm) Tool: HSK-A63 2 x 40 places
used
x-travel:600 mm y-travel:770 mm z-travel:675 mm total power requirement:47 kW weight of the machine ca.:13 t Tool bore:HSK-A63 numbers of tools in magazin:40 including additional tool magazine ZM 182 1 spindle , 5 axes
used
x-travel:630 mm y-travel:630 mm z-travel:500 mm number of spindle speeds:0 - 15000 spindle motor:32 kW size of pallet:500 x 500 mm b-axis:36000 x 0,001 ° no. of workpieces in the magazine:61 Stück tool taper:HSK 63 weight of the machine ca.:15 t Double-Spindle Mechanical processing cylinder head VR6
